Image preview - the first page of the document
>> Download 02-nsb-9-gen documenatation <<
Text preview - extract from the document
CCS Technical Documentation
NSB-9 Series Transceivers
General Information
Issue 1 04/03 Nokia Corporation
NSB-9
CCS Technical Documentation
Table of Contents
Page No
NSB-9 Product Selection ............................................................................................... 3
Accessories List ............................................................................................................. 4
Technical Specifications ................................................................................................ 5
General Specifications of Transceiver NSB-9 .............................................................5
Environmental conditions ......................................................................................... 6
Transceiver Features ....................................................................................................6
Electrical Characteristics .............................................................................................7
Page 2 Nokia Corporation Issue 1 04/03
NSB-9
CCS Technical Documentation
NSB-9 Product Selection
The NSB-9 is a dualband radio transceiver unit designed for the GSM850 and GSM1900
networks. GSM850 power class is 4, GPRS850 power class is 5 and GSM1900 power class
is 1. It is a true DCT-4 based transceiver with new advanced features.
NSB-9 Product and modules
Name Module name Module code
Basic transceiver NSB-9 0508623
Radio module RM9 0202046
Flip NHL-6 Flip 0262868
Flip NSB-9 Flip basic LTA 9458924
NSB-9 Flip basic CAN 9459047
Mechanics assembly parts NSB-9 HDB58 0262884
Software module ( basic SW ) SW NSB-9 basic 0243727
mech.module
Figure 1: NSB-9 transceiver
Issue 1 04/03 Nokia Corporation Page 3
NSB-9
CCS Technical Documentation
Accessories List
Batteries Product code:
Semi-fixed Battery BLC-2 1000mAh 0670403
Chargers Product code:
Travel Charger ACP-12E (EUR) 0675294
Travel Charger ACP- 12X (UK) 0675296
Travel Charger ACP-12U (US) Made in country 0675303
Travel Charger ACP- 12UB (US) (Countries like Brazil/Portugal) 0675293
Travel Charger ACP-12G (US) (Countries like Brazil/Gradient) 0675295
Travel Charger ACP-12K (Korea) 0675301
Travel Charger ACP-12AR (Argentina) 0675298
Travel Charger ACP-12A (Australia) 0675300
Mobile Charger LCH-12 0675328
Note! ACP-7, ACP-8, and LCH-8 chargers are also compatible with NSB-9
Portable and Office Accessories Product code:
Boom Headset HDB-4 0694094
Stereo Headset HDS-3 0694093
Loopset LPS-4 0630443
DCV-14 Connectivity Stand 0273869
DT-1 Music Stand 0694119
Mobile Accessories: Product code:
Mobile Holder MBC-13L 0650048
Swivel Mount HHS-15 0620060
Car Installation Kit 126 CARK126 (Full Car Kit providing charging) 0085197
Handsfree Unit HFU-4 0694103
HF Microphone HFM-8 0690016
External HF Speaker HFS-12 0692009
Mounting Plate MKU-1 0620036
System Cable SCU-4 0630471
Power Cable PCU-4 0630478
Other Accessories: Product code:
Connectivity Cable DKU-5 (FBUS /USB Cable) 0730235
PC Suite
Carrying accessories
Page 4 Nokia Corporation Issue 1 04/03
NSB-9
CCS Technical Documentation
Technical Specifications
General Specifications of Transceiver NSB-9
Dimensions (mm) Weight Volume
Unit
(L x W x T) (g) (cm3)
NSB-9 Transceiver with BLC-2 bat- 55 x 117 x 22.5 122 105
tery pack
Parameter Unit
Cellular System GSM850, GSM1900
RX Frequency Band GSM850: 869.2 - 893.8 MHz
GSM1900: 1930.2 - 1989.8 MHz
TX Frequency Band GSM850: 824.2 - 848.8 MHz
GSM1900: 1850.2 - 1909.8 MHz
Output Power GSM850 : +5 ...+33 dBm / 3.2 mW ... 2 W
GSM1900: +0 ...+30 dBm / 1.0 mW ... 1 W
Number of RF Channels GSM850: 124
GSM1900: 299
Channel Spacing 200 kHz
Number of TX Power Levels GSM850 *: 15
GSM1900: 16
Talk time
Battery : BLC-2 up to 4.5 hours
Talk time variations:
Integrated Handsfree (IHF) talk time up to 4 hours
Standby time
Battery: BLC-2 up to 10 days (240 hours)
Radio + headset up to 30 hours
Radio + IHF up to 16 hours
Variation in operating times may occur depending on SIM card, network and usage set-
tings, usage style and environments.
Issue 1 04/03 Nokia Corporation Page 5
NSB-9
CCS Technical Documentation
Environmental conditions
Environmental condition Ambient temperature Notes
Normal operation -10 oC ... +55 oC Specifications fulfilled
Reduced performance +55 oC ... +65 oC Operational only for short periods
Intermittent operation -20 oC ... -10 oC and Operation not guaranteed but an attempt to
operate will not damage the phone
+65 oC ... +80 oC
No operation -40 oC ... -20 oC Operation not possible but an attempt to
operate will not damage the phone
No operation or storage < -40 oC and > +80 oC No storage; an operation attempt may cause
permanent damage
Charging allowed -25 oC ... +60 oC
Long term storage conditions 0 oC ... +40 oC
Transceiver Features
Transceiver main HW parts / features include:
