Image preview - the first page of the document
>> Download 01-rh23-genl documenatation <<
Text preview - extract from the document
Customer Care Solutions
RH-23 Series Transceivers
General Information
Issue 1 03/2004 Company Confidential Nokia Corporation
RH-23 Company confidential
General Information CCS Technical Documentation
Table of Contents
Page No
RH-23 Product Selection ...............................................................................................3
Accessories List .............................................................................................................4
Technical Specifications ................................................................................................6
General Specifications of Transceiver RH-23 .............................................................6
Battery endurance ......................................................................................................7
Environmental conditions .........................................................................................7
Transceiver Features ....................................................................................................8
Electrical Characteristics .............................................................................................9
Page 2 Nokia Corporation. Issue 1 03/2004
Company confidential RH-23
CCS Technical Documentation General Information
RH-23 Product Selection
The RH-23 is a Dual Band transceiver unit designed for the EGSM900, GSM1800 (EDGE)
networks. It is a GSM900 phase 2 power class 4 transceiver (2W) and a GSM1800 power
class 1 (1W) transceiver. It is also an EDGE900 power class E2 (0.5W/27dBm) and an
EDGE1800 power class E2 (0.4W/26dBm) transceiver.
RH-23 Product and modules
Material code/
Name Type code Module code
module type
Basic transceiver RH-23 0509448
Radio module 1AQ 0202075
UI board 1BF 0210012
Mechanics assembly parts 0263173
Software module (basic SW) On Flash memory
Figure 1: RH-23 transceiver
Issue 1 03/2004 Nokia Corporation. Page 3
RH-23 Company confidential
General Information CCS Technical Documentation
Accessories List
Batteries Product code:
Battery BL-4C 780mAH Li-Ion 0670386
Chargers Product code:
AC Travel Charger ACP-7E (EUR) 207-253 Vac 0675144
AC Travel Charger ACP-7U (US) 108-132 Vac 0675143
AC Travel Charger ACP-7C (China) 198-242 Vac 0675158
AC Travel Charger ACP-7X (UK) 207-253 Vac 0675145
AC Travel Charger ACP-7H (Hong Kong) 180-220 Vac 0675146
AC Travel Charger ACP-7A (AUS) 216-264 Vac 0675148
Performance Travel Charger ACP-8E (EUR) 90-264 Vac 0675195
Performance Travel Charger ACP-8K (Korea) 90-264 Vac 0675199
Performance Travel Charger ACP-8X (UK) 90-264 Vac 0675197
Performance Travel Charger ACP-8U (US) 90-264 Vac 0675196
Performance Travel Charger ACP-8C (China) 90-264 Vac 0675211
Performance Travel Charger ACP-8A (Australia) 90-264 Vac 0675214
Performance Travel Charger ACP-9E (EUR) 0675149
Performance Travel Charger ACP-9U (US) 0675151
Performance Travel Charger ACP-9X (UK) 0675150
Performance Travel Charger ACP-9A (AUS) 0675152
Performance Travel Charger ACP-9J (Japan) 0675153
Performance Travel Charger ACP-9UR (US) 0675159
Performance Travel Charger ACP-9UJ (Brazil) 0675169
Performance Travel Charger ACP-9C 0675204
Performance Travel Charger ACP-9UB 0675224
Performance Travel Charger ACP-9G (Brazil) 0675225
ACP-12E Travel Charger (EUR) 90-264 Vac 0675294
ACP-12X Travel Charger (UK) 90-264 Vac 0675296
ACP-12U Travel Charger (US) 90-264 Vac 0675303
ACP-12UB Travel Charger (Brazil) 90-264 Vac 0675203
ACP-12G Travel Charger (US) 90-264 Vac 0675295
ACP-12C Travel Charger (China) 90-264 Vac 0675297
ACP-12A Travel Charger (Australia) 90-264 Vac 0675300
Page 4 Nokia Corporation. Issue 1 03/2004
Company confidential RH-23
CCS Technical Documentation General Information
ACP-12AR Travel Charger (Argentina) 90-264 Vac 0675298
AC-1E Retractable Charger 0675349
AC-1X Retractable Charger 0675350
AC-1U (also Brazil and Japan) Retractable Charger 0675351
AC-1C Retractable Charger 0675353
AC-1A Retractable Charger 0675354
AC-1AR Retractable Charger 0675355
Audio and Car Enhancements Product code:
HDB-4 Boom headset 0694094
LPS-4 Inductive Loopset 0630443
HDS-3 Stereo Headset 0694093
HS-10 Retractable Headset 0694126
AD-5B Wireless Audio Adapter 0694149
BHF-1 Headrest Handsfree (APAC only) 0694102
LCH-9 Mobile Charger 0675120
LCH-12 Mobile Charger 0675328
Style packs for covers, Imagewear and Imaging Product code:
CC-182D Brown 1 0274845
CC-184D Brown 2 0274844
CC-183D Grey 1 0274846
CC-181D Grey 2 0274847
CC-179D Black 1 0274848
CC-180D Black 2 0274849
RX-3 Medallion 1 0630702
RX-4 Medallion 2 0274765
RX-11 Kaleidoscope 0274768
SU-4 Image Frame 0274728
SU-7 Image Frame 0274757
Inbox/Sales Package Enhancements Product code:
CP-8 Wrist strap and soft pouch Brown 0720375
CP-8 Wrist strap and soft pouch Black 0720376
CP-8 Wrist strap and soft pouch Grey Blue 0720377
English label, white 0694156
Issue 1 03/2004 Nokia Corporation. Page 5
RH-23 Company confidential
General Information CCS Technical Documentation
English label, black
Data Product code:
DKU-5 Connectivity Adapter Cable 0730235
Technical Specifications
General Specifications of Transceiver RH-23
Dimensions (mm) Weight Volume
Unit
(L x W x T) (g) (cm3)
Transceiver with BL-4C 780mAh Li- 86 x 50 x 26 115 91
Ion battery pack
Table 1: Main RF characteristics
Parameter Unit and value
Cellular system EGSM900/GSM1800
RX Frequency range EGSM900: 925... 960 MHz
GSM1800: 1805...1880 MHz
TX Frequency range EGSM900: 880... 915 MHz
GSM1800: 1710...1785 MHz
Duplex spacing EGSM900: 45 MHz
GSM1800: 95 MHz
Channel spacing 200 kHz
Number of RF channels EGSM900: 174
GSM1800: 374
Output Power EGSM900: GSMK 5...33 dBm
EGSM900: 8-PSK 5...27 dBm
GSM1800: GSMK 0...30 dBm
GSM1800: 8-PSK 0...26 dBm
Number of power levels GSMK EGSM900: 15
GSM1800: 16
Number of power levels 8-PSK EGSM900: 12
GSM1800: 14
Page 6 Nokia Corporation. Issue 1 03/2004
Company confidential RH-23
CCS Technical Documentation General Information
Battery endurance
Nokia measurements of the operational times in GSM 900/ 1800 are:
Talk time*
