Image preview - the first page of the document
>> Download 01-nmm3-gen documenatation <<
Text preview - extract from the document
Customer Care Solutions
NMM-3 Series Transceivers
1-General Information
Issue 1 (11/2003) Copyright 2003 Nokia Corporation Page 1-1
Company Confidential
NMM-3 Company Confidential
1-General Information CCS Technical Documentation
Table of Contents
Page
No
Product Selection .................................................................................... 3
Handportables ............................................................................... 3
Product key features .............................................................................. 3
Display and keypad ....................................................................... 3
Hardware characteristics ............................................................ 3
UI features ...................................................................................... 4
Power management ..................................................................... 5
Mechanical dimensions .............................................................. 5
Accessories (Mobile Enhancements) ................................................. 5
Page 1-2 Copyright 2003 Nokia Corporation Issue 1 (11/2003)
Company Confidential
Company Confidential NMM-3
CCS Technical Documentation 1-General Information
Product Selection
Handportables
The NMM-3 (Nokia 7600) is a Tri-band handportable mobile imaging telephone for the
GSM900/1800 and WCDMA 3GPP networks.
Figure 1: NMM-3 Phone
Product key features
Display and keypad
