Image preview - the first page of the document
>> Download 01-rh37-general documenatation <<Text preview - extract from the document Nokia Customer Care
RH-37 Cellular Phones
1 - General Information
Issue 1 07/04 2004 Nokia Corporation. Page 1
Company Confidential
RH-37 Company Confidential
1 - General Information Nokia Customer Care
This page has been intentionally left blank
Page 2 2004 Nokia Corporation. Issue 1 07/04
Company Confidential RH-37
Nokia Customer Care 1 - General Information
Table of Contents
Page No
RH-37 Product Selection....................................................................................................................... 5
RH-37 product and modules ............................................................................................................. 5
Supported accessories ......................................................................................................................... 6
Environmental conditions .................................................................................................................. 7
Transceiver features ............................................................................................................................. 7
Issue 1 07/04 2004 Nokia Corporation. Page 3
RH-37 Company Confidential
1 - General Information Nokia Customer Care
This page has been intentionally left blank
Page 4 2004 Nokia Corporation. Issue 1 07/04
Company Confidential RH-37
Nokia Customer Care 1 - General Information
RH-37 Product Selection
The RH-37 is a triple band monoblock transceiver unit, designed for EGSM900,
GSM1800 and GSM1900 EDGE networks. It is a GSM900 phase 2, power class 4 (2W)
transceiver and a GSM1800/1900 power class 1 (1W) transceiver. It is also an EDGE900
power class E2 (0.5W/27dBm) and an EDGE1800/1900 power class E2 (0.4W/26dBm)
transceiver.
RH-37 product and modules
Name Type Code Material Code
Basic transceiver RH-37 0516128
Printed Wiring Board (PWB) module 1CN 0202178
Mechanics module 0263468
Software module 8457773
Figure 1: RH-37 Transceiver
Issue 1 07/04 2004 Nokia Corporation. Page 5
RH-37 Company Confidential
1 - General Information Nokia Customer Care
Supported accessories
Product Type Description Comment
AC-1E Retractable charger
ACP-7 E&A, APAC = Standard Charger,
Americas = Standard Travel Charger
ACP-8 E&A = Travel Charger,
APAC = Fast & Light Charger
ACP-12 Travel Charger
AD-5B Wireless Voice Adaptor
BHF-1 Headrest Handsfree
BHF-3 Headrest Handsfree
BL-5B Battery Eur/Afr & Apac English type label
Battery France French type label
Battery Americas English type label
Battery China Chinese type label
Battery Brazil Portuguese type label
DKU-5 Connectivity Adapter Cable
DT-6 Call forwarding deskstand
HDB-4 Boom Headset
HF-2 Activity Handsfree
HF-3 Plug-in Handsfree
HS-2R Radio Headset
HS-3W Wireless Headset
HS-5 Headset
HS-10 Retractable Headset
LCH-9 E&A, APAC = Mobile Charger
LCH-12 E&A, APAC = Mobile Charger
LPS-4 Inductive Loopset
HDA-10 Pop-portTM to tty adapter
PT-5W Digital Camera
SU-5 TV image viewer
FunctionlaCover "0b" colour 2
FunctionlaCover "0b" colour 3
Cut-out Cover Emo-Dance
Cut-out Cover Blue Sq.
Cut-out Cover Red Flwr
Nokia Observation Camera
Note: No car kit support.
Page 6 2004 Nokia Corporation. Issue 1 07/04
Company Confidential RH-37
Nokia Customer Care 1 - General Information
Environmental conditions
Environmental Condition Ambient Temperature Notes
Normal operation -10
