Image preview - the first page of the document
>> Download 02-nem2-gen documenatation <<
Text preview - extract from the document
CCS Technical Documentation
NEM-2 Series Transceivers
General Information
Issue 01 07/03 Nokia Corporation
NEM-2
CCS Technical Documentation
Table of Contents
Page No
NEM-2 Product Selection .............................................................................................. 3
Accessories List ............................................................................................................. 4
Technical Specifications ................................................................................................ 5
General Specifications of Transceiver NEM-2 ............................................................5
Battery endurace........................................................................................................ 5
Environmental conditions ......................................................................................... 6
Transceiver Features ....................................................................................................6
Electrical Characteristics .............................................................................................7
Page 2 Nokia Corporation Issue 01 07/03
NEM-2
CCS Technical Documentation
NEM-2 Product Selection
The NEM-2 is a dual Band transceiver unit designed for the GSM850/ DCS1900 net-
works. The RF requirements follow ETSI GSM850/DCS1900 specifications. The phone
supports GPRS protocols and multi slot classes from 1 to 4. The phone is a power class 4
transceiver (2W).
The product is an entertainment and media phone, with focus on audio, gaming and
messaging. It features a music recorder/player with stereo FM radio.
NEM-2 Product and modules
Material code/
Name Type code Module code
module type
Basic transceiver Nokia NEM-2 0508530
Engine module EM21 0201917
UI module EM20 0201970
Mechanic assembly parts 0262996
MCU software module 0243560
ADSP software module 0243561
Figure 1: NEM-2 transceiver
Issue 01 07/03 Nokia Corporation Page 3
NEM-2
CCS Technical Documentation
Accessories List
Batteries Product code:
Battery BLD-3 720mAH Li-Ion 0670352
Chargers Product code:
AC Travel Charger ACP-7E (Chile, Bolivia, Peru) 207-253 Vac 0675144
AC Travel Charger ACP-7U (US) 108-132 Vac 0675143
AC Travel Charger ACP-7AR (Argentina) ? Vac 0675244
ACP-12E Travel Charger (Chile, Bolivia) 90-264 Vac 0675294
ACP-12U Travel Charger (US) 90-264 Vac 0675303
ACP-12UB Travel Charger (Brazil) 90-264 Vac 0675293
ACP-12AR Travel Charger (Argentina) 90-264 Vac 0675298
Portable Accessories Product code:
Stereo Headset HDS-3 0694093
Stereo Headset HDS-3H 0694138
Boom Mono Headset HDB-4 0694094
Stereo Audio Line-in cable ADE-2 0630464
USB-cable DKU-2 0730238
Inductive Loopset LPS-4 0630443
Cigarette Lighter Charger LCH-9 0675120
TTY Accessory HDA-10 0694115
MMC cards Product code:
MMC-card DTS-16 0630419
MMC-card DTS-32 434B044
MMC-card DTS-32 434B106
MMC-card DTS-64 434B107
Page 4 Nokia Corporation Issue 01 07/03
NEM-2
CCS Technical Documentation
Technical Specifications
General Specifications of Transceiver NEM-2
Dimensions (mm) Weight Volume
Unit
(L x W x T) (g) (cm3)
Transceiver with BLD-3 720mAh Li- 114.7 x 66.5 x 20.9 126 114.9
Ion battery pack
Parameter Unit
Cellular System GSM850, GSM1900
RX Frequency Band GSM850: 869 - 894 MHz
GSM1900: 1930 - 1990 MHz
TX Frequency Band GSM850: 824 - 849 MHz
GSM1900: 1850 - 1910 MHz
Output Power GSM850 : +5 ...+33 dBm / 3.2 mW ... 2 W
GSM1900: +0 ...+30 dBm / 1.0 mW ... 1 W
Number of RF Channels GSM850: 124
GSM1900: 300
Channel Spacing 200 kHz
Number of TX Power Levels GSM850 : 15
GSM1900: 16
Battery endurace
Nokia measurements of the operational times in GSM 850/ 1900 are:
Talk time
Battery : BLD-3
Talk time variations:
Integrated Handsfree (IHF) talk time
Standby time
Battery: BLD-3
Radio + HDS-3
Radio + IHF
Variation in operating times may occur depending on SIM card, network and usage set-
tings, usage style and environments. Talk time is increased by up to 30% if half rate is
Issue 01 07/03 Nokia Corporation Page 5
NEM-2
CCS Technical Documentation
active and reduced by 5% if enhanced full rate is active.
Note: Volume level 7 used in calculation. Calculated from talk times.
Note: Volume level 7 used in calculation. Phone idle.
Environmental conditions
Environmental condition Ambient temperature Notes
Normal operation -10 oC ... +55 oC Specifications fulfilled
Reduced performance +55 oC ... +65 oC Operational only for short periods
Intermittent operation -20 oC ... -10 oC and Operation not guaranteed but an attempt to
operate will not damage the phone
+65 oC ... +85 oC
No operation -40 oC ... -20 oC Operation not possible but an attempt to
operate will not damage the phone
No operation or storage < -40 oC and > +85 oC No storage; an operation attempt may cause
permanent damage
Charging allowed -25 oC ... +60 oC
Long term storage conditions 0 oC ... +40 oC
Transceiver Features
Transceiver main HW parts / features include:
