CONFIDENTIAL 1 (1)
Nokia Mobile Phones Service Bulletin No. SB-019/30.03.01
Technical Support, Europe & Africa
NHM-3
IMPROVEMENT ON CARKIT DETECTION
In some cases the phone has not started charging, when placing the phone
in power off -state to Active Car Holder (MCC-2). Only phones with layout
version SM4_15 can suffer from this occasional insufficient detection.
Following change can improve the detection and it has been implemented in
production since serial number 350001/15/105600/3:
Assemble resistor R260 to the place of unassembled capacitor C260 (see
picture below)
When phone is in Power On -state, resistor R260 is shorted by transistor
V221, but when phone is in Power Off -state, carkit detection is made by
pulling down SGND-line with resistor R260.
ITEM CODE DESCRIPTION
Add R260 1430772 CHIPRES 0W06 5K6 J
NHM-3 SB-019
