Nokia Mobile Phones Service Bulletin No. SB-013/01.03.00
Technical Support, Europe & Africa
NSE-5
NEW SERVICE SOFTARE VERSION 241.08.00
New service software version 241.08.00 has been released for NSE-5.
Changes made from version 241.07.00 to version 241.08.00:
- PCI2 layer is version 05.04.04.
- Improvement in OTA ringing tones handling
- The dialog box handling User Settings And Data Transfer has been
expanded. It is possible to select specific settings to transfer. When
restoring settings from file the user have to select the same settings (see
the picture below)
- Changes in SMS's transfer with future MCU SW versions (MCU SW
version > 4.77)
CODE DESCRIPTION
0774234 SW SERVICE NSE-5 3'' DISK
Notes:
1. If problems arise when downloading Calling Line Icons (CLI) after flashing:
- If download of CLI fails after flashing the phone UI probably needs
to be initialised. Select menu items and . Then try to download CLI.
NSE-5 SB-013
CONFIDENTIAL 2 (2)
2. If problems arise when downloading Wake Up Graphics (WUG) after
flashing:
- If downloading of WUG fails after flashing then close the "Restore
Default User Setting" Dialog and the Flash dialog. Select menu
items and check mark
"Graphical Welcome Message" and select
3. If problems arise with Call Registers after flashing:
- If Call registers do not work after flashing the phone UI probably
needs to be initialised. Select menu items and . If it still not work then try to re-flash the
phone and give the phone time to wake up etc during flashing.
4. If problems arise when flashing with FPS-4:
- If there is a ROM- or PPM checksum failure a dialog will pop-up
and say so. In that case the phone will not wake up by itself. You
can try to turn on the phone and select and
and run MCU ROM Checksum- and PPM Checksum test. It they
pass the phone is probably OK and it only needs reflashing.
5. User Settings transfer fails:
- MCU SW version > 4.73 : No SIM needed
- MCU SW version 6,0 QHHGHG WR WUDQVIHU :$3VHWWLQJV
NSE-5 SB-013
