                                                 CONFIDENTIAL                  1 (1)




Nokia Mobile Phones                              Service Bulletin No. SB-023/28.08.00
Technical Support, Europe & Africa

                                                 NSE-5


WRONG CODE IN SERVICE MANUAL

               Service manual for NSE-5 includes wrong code for (G701) VCTCXO. Only
               the following component can be used as a spare part (ref NSE-5 SB-002):

               ITEM      CODE         DESCRIPTION
               G701      4510217      VCTCXO 13.000MHZ+-5PPM 2.8V




               Note: Code 4510229 should not be used when ordering VCTCXO for
               NSE-5.
