Image preview - the first page of the document
rm14-007


>> Download rm14-007 documenatation <<

Text preview - extract from the document
                                                   CONFIDENTIAL                      1 (2)




Customer and Market Operations                     Service Bulletin No. SB-007/22.02.05
EMEA Customer Care

                                                   RM-14




DISASSEMBLY INSTRUCTIONS FOR SLIDE COVER

               If the slide cover needs to be disassembled e.g. for IMEI check, please follow
               the below described instructions.

               1. Use the SIM tray tool to open the SIM holder.




               2. Open the slide cover




               3. Use the SRT-6 as a lever to remove the slide cover.




 x   Level 1    x   Level 2      Level 3      Level 4                                        Ref.

RM-14 SB-007                                                  Copyright
