NSM3-005


>> Download NSM3-005 documenatation <<

Text preview - extract from the document
                                                    CONFIDENTIAL                      1 (1)




Nokia Mobile Phones                                 Service Bulletin No. SB-005/17.12.99
Technical Support, Europe & Africa

                                                    NSM-3


MOUNTING OF THE LCD MODULE ASSEMBLY

               When mounting the LCD module assembly to the radio module PCB, it is
               recommeneded to notice the following procedure:

               Check that the edge of the LCD module assembly metal frame does not stay
               on the PCB. Check that on both sides of the keyboard area.




               If the installation has not been checked and the module is installed inclined, it
               can cause keyboard problems: when pressing keys there is no response or
               the needed effort is too high.




NSM-3 SB-005
