Image preview - the first page of the document
NSM3-040


>> Download NSM3-040 documenatation <<

Text preview - extract from the document
                                                    CONFIDENTIAL                     1 (1)




Nokia Mobile Phones                                 Service Bulletin No. SB-040/27.12.00
Technical Support, Europe & Africa

                                                    NSM-3


TWIN RIP

               Support part for bottom connector (Twin Rip) has been added into NSM-3
               assembly parts and is available as a spare part.

               Installation




               When putting the support part in its place, check that the long side of the twin
               rip will be in vibra motor's side and that the support part is in the bottom of
               the SIM connector.




               CODE            PG      DESCRIPTION
               9660147         17      TWIN RIP DMD06257




NSM-3 SB-040
