Image preview - the first page of the document
NHM5-006


>> Download NHM5-006 documenatation <<

Text preview - extract from the document
                                                   CONFIDENTIAL                  1 (1)




Nokia Mobile Phones                                Service Bulletin No. SB-006/02.10.00
Technical Support, Europe & Africa

                                                   NHM-5


CORRECT ORDERING CODE FOR D-COVER

               Correct spare part ordering code for D-cover is following:

               CODE         DESCRIPTION
               9490229      D-COVER SPARE PART DMC03205

               Note: Code for D-cover mentioned in SB-002 should not be used, as in that
               code D-cover is without release springs (see picture below) and can not be
               used for service purposes!




NHM-5 SB-006
