Image preview - the first page of the document
>> Download 3600s_RM352_schematics_v1_0 documenatation <<
Text preview - extract from the document
Service Schematics
Introduction
Important:
This document is intended for use by authorized service centers only.
Table of contents
"Service Schematics" was created with focus on customer care.
The purpose of this document is to provide further technical repair information for
NOKIA mobile phones on Level 3/4 service activities.
RM-352 Frontpage
System & USB connector
1
2
It contains additional information such as e.g. "Component finder". Betty, AVilma, audio, SIM & battery 3
Bluetooth, Radio, MicroSD & Camera 4
RAPS 5
Saving process time and improving the repair quality is the aim of this document.
It is to be used additionaly to the service manual and other training UI 6
or service information such as Service Bulletins.
RF part 7
Component finder 8
While every endeavour has been made to ensure the accuracy of this document, some
errors may exist. If the reader finds any errors, NOKIA should be notified in writing.
Please send E-Mail to: [email protected]
