Image preview - the first page of the document
nokia_monoplus110. 7156


>> Download nokia_monoplus110. 7156 documenatation <<

Text preview - extract from the document
                                                      TV
STEREO CHASSIS
MONO PLUS


GB Service manual
                              34 @I Manuel de service
                                                           1995




@ Service-Manual                 (I% Manuale di servizio
(32 Serviceanvisning


NOKIA                  5556    6356        7156




                       CONNECTINGPEOPLE
Instructions for repair work                                                              Consigli per le riparazioni
N.6.: switch-model
    (cc.                                                                                  Attenzione! (circ. alimentazionel
Please use only original component 3447 00 04 for CO06. If standard size                  Utilizzare soltanto pezzo orig. 3447 00 04 CO06. Nei Elko COO6 reperibili in
electrolyt capacitor COO6 is used, parallel 0,47 FF MKT must be installed                 commercio deve essere ulteriorm. e montato un
additionally.                                                                             0,47pF MKT.
1. With the horizontal output stage disconnected (e.g. pin 8 at TK02 open)                1. Con lo stadio di uscita orizzontale staccato (ad es. collegamento                 8 al
   and a "dummy" load at the cathode of V031 (e.g. 100 W lamp) the                           TK02 aperto) e un carico di sostituzione al catodo di V031 (una lampada
   power supply must supply approx. 100% of the setpoint voltage.                            a 100 W), I'alimentatore          deve fornire circa il 100% della tensione
2. For fault finding the elect. fuse can be disconnected with a shunt                         nominale.
   connection across CO07. IF the electronic fuse cuts out due to a                       2. Per la ricerca di errori in case di funzionamento            di sicurezza del blocco
   momentary     overload, the TV set can be re-started by using the mains                   dileeralimentazione,       COO7 pub essere cavallottato.          Se il funzionamento
   switch.                                                                                   di sicurezza dovesse scattare a causa di un sovraccarico transitorio,
3. Make sure there is hum-free d. c. voltage available. For example: the                      I'apparecchio     pub essere rimesso in funzione azionando I'unterruttore
   ripple voltage of Ul is approx. 4 V and should, due to capacitance loss                    principale d'inserzione e disinserzione.
   _. ____, ..- increase ..-_.. ..-._.
   nf CO33. nnt_..._._ -__ much more. The rioole voltaoes of the other d.c.
                                               rr_ ._ ._LI__ _                            V. rnntrnll=rn
                                                                                          `z ""IILIVIIUI"   Yll" I" t~neinni
                                                                                                            ,-hn la LYII"I"III    mntinlua
                                                                                                                                  IVII~IIIUI ciann n&m
                                                                                                                                             "l"lI" y,,.u rli mn7in
                                                                                                                                                          "I I"I.LI".  I "I "1 ."
                                                                                                                                                                       Pmr me 1.

   voltages should be less than 1 V. The ripple voltages of U2, U3, U5 are                   tensione di ronzio di Ul si trova a ca. 4 V e non dovrebbe aumentare di
   in the mV range.                                                                          molto, in dipendenza della perdita di capacite di C033. Le tensioni di
                                                                                             ronzio delle rimanenti tensioni continue dovrebbero     rimanere inferiori a
                                                                                             1 V. La tensione di ronzio di U2, U3, U5 si trovano nel campo dei mV.




Reparatutiips
Achtung! (betr. Schaltnetzteill
Fiir COO6 nur Originalteil 3447 00 04 verwenden.         Bei handelsiiblichem      Elko   Reparationstips
COO6 mul3 parallel 0,47 FF MKT zusltzlich besttickt werden.                               Ohs! lgiller switch-nltdelenl
1. Mit abgetrennter    Horizontalendstufe     (z.B. AnschluB 8 an TK02 offen)             Endast originalkomponent          3447 00 04 bBr anvlndas f6r CO06. Om en
    und einer Ersatzbelastung     an der Kathode von                                      standard elektrolytkondensator         anvlnds f6r CO06, m&ste en
    V031 (100 W Glijhlampe)      muR das Netzteil ca. 100% der Sollspannung               0,47 FF MKT installeras parallellt.
    liefern.                                                                              1. Med horisontalslutsteget        urkopplat (t.ex. stift 8 p8 TK02 ijppen) och
2. Zur Fehlersuche bei Sicherungsbetrieb         des Netzteiles kann COO7                    konstbelastning      (t.ex. 100 W lampa) pd katoden till V031, mlste
    iiberbrtickt werden. Wurde der Sicherungsbetrieb          durch einen fltichti-          nstdelen mata ca, 100% av den nijdvlndiaa             soinninoen,
    gen ijberlastfall ausgel6st. kann das Gerit durch Aus- und Einschalten                2. F6r felsijkning kan skyddskretsen        kopplas ur funktion med en
    des Netzschalters wieder in Betrieb genommen werden.                                     bryggkoppling      Bver CO07. Om skyddskretsen          utl6ser sig, beroende pa
3. Auf brummfreie     Gleichspannung      achten. Z.B. die Brummspannung          von        en tillflllig Bverbelastning,     kan mottagaren     kopplas pB pB nytt med
    Ul liegt bei ca. 4 V und sollte, bedingt durch KapazitCtsverlust        von              nltbrytaren.
    C033, nicht viel grdRer werden. Die Brummspannungen             der ijbrigen          3. Anvtind endast filtrerad DC-spinning.         Exempel: Beroende pB
    Gleichspannungen     sollten unter 1 V liegen. Die Brummspannungen             von       kapasitansfijrlusten      aver C033, fdr brumniven pB Ul inte vara dver 4 V.
    U2, U3 und U5 liegen im mV-Bereich.                                                      Brumniven pd iivriga DC-splnningarna            skall vara under 1 V. Brumniven
                                                                                             pB U2, U3 och U5 Br i mV storlek.




Conseils de reparation
Attention! (bloc secteur de commutationl
Utiliser uniquement       la pice originale 3447 00 04 (COO6). Dans le cas de
condensateurs      electrochimiques      usuels COO6 0,47pF MKT doit etre equip6
en plus.
1. Lorsque 1'6tage final horizontal est dbconnectb (par ex. raccordement          8
   sur TK02 ouvert) et dans le cas d'une charge de remplacement            au
   niveau de la cathode de V031 (lampe B incandescence             de 100 W) le bloc
   seteur doit delivrer 100% env. des tensions de consigne.
2. Pour la detection d'erreurs en fonctionnement         de s&uritb du bloc
   secteur, il est possible de ponter CO07. Lorsque le fonctionnement          de
   sDrete est d&lenchb B cause d'une surcharge transitoire, I'appareil peut
   gtre remis en marche au moyen du commutation             principal mise en et
    hors circuit.
3. Veiller B la presence de tensions continues exemptes d'ondulation.          La
   tension d'onduiation de Ui par exempie est de 4 V env. et ne devrait pas
    beaucoup augmenter en raison d'une perte de capacite de C033. Les
   tensions d'ondulation des autres tensions continues devraient toujours
    dtre infbrieures B 1 V. Les tensions d'ondulation de U2, U3, U5 se situent
    dans la gamme des mV.
Service adjustments                                                                  Other service adjustments
Note! Before other adjustments Ul voltage must be adjusted.
                                                                                     Horizontal amplitude
If the set cannot be switched on with the number buttons, please see
                                                                                     Adjust hor. amplitude        to coil LK 12   ( 21") or to resistor RK66 (25". 28").
under "MODE" (Service menu 3).
                                                                                     Vertical amplitude
Service mode                                                                         Adjust vertical   amplitude     to resistor RS20.
Select the service mode by pressing the Mute,       OK (M) and TV buttons on
the remote control unit. You can use the yellow      button to call up Service       Vertical position
Menu 23 or 4 (or Service Menu 1 again).                                              Adjust vertical   position    by severing     resistor RS24 and/or    RS14.
Use the cursor button A or v to select required       adjustment    and adjust it    Pincushion distortion correction (25". 28" 1
by using the cursor buttons 4 and p.
                                                                                     Adjust pincushion     distortion    correction    to resistor RK60.
Store into memory by pressing the red OK (M)        button.
Return to normal TV mode by pressing the TV         button.                          Focus
                                                                                     Use focus adjuster TK02 (at horizontal           transformer)   to set the focus to
Service adjustment which are made in service mode
                                                                                     optimum sharpness.
 DSD           Note
                                                                                     G2
               Servicemenu 1                                                         1. Test picture with medium beam current, e.g. Fubeka or Philips test
 Ul            Ul operating voltage, see adjustment "Ul voltage"                        picture. Contrast, brightness, colour saturation to ideal setting.
 4GC           See adjustment "AGC"                                                  2. Determine the colour cathode with the highest blacklevel measuring
 H-SHIFT       Adjust centre of the test picture horizontal to a centred position.      pulse.
               (Advice on set software)                                              3. Use the G2 adjuster to set the measuring pulse to 140 V t/- 2 V.

               Servicemenu 2                                                         AFC
 TXT           Teletextcharacter sets: EASTIWESTMIESTTURK                            1. Feed in symmetr. IF signal by means of 4:l transmitter  at test points
 SCART         SCART socket, YES/l=When a switching voltage is being                    XLO3/04 (BG, DK standard 38.9 MHz or the I standard 39.5 MHz;
               received at pin 8 (+I2 V), the set switches from standby to the          approx. 0.8 Vpp).
               "ON" operating status (programme memory location El).                 2. At test point XL01 (XL02 ground), set to 3.5 V DC f 0.5 V with coil ZLOl
               YES/S=as for YES/l; however, the set switches back to the                (AFC reference).
               standby operating status when the switching voltage fat pin 8) is
               switched off. This does not apply if you have changed programmE       AFC check
               during operation.                                                     Retune the IF signal to approx. 39 MHz (39.7 MHz); when you do this, the
               NO=El cannot be selected.                                             voltage must drop to approx. 1 V.
 TXT H-SHIFT   Adjust teletext picture horizontal to centre on the screen.
                                                                                     Sound
 APS           Set to the appropriate television standard.
                                                                                     The BG or I standards are independent    of the STANDARD set. With the
               Specifies APS sequence, e.g. first the BG standard, then L or L,
               and then BG.                                                          BG/DK standard: STANDARD 2 = DK and STANDARD 3 = BG.
                                                                                     To set the STANDARD,    proceed as follows:
               Servicemenu 3                                                         1. Press the PROG button (RCF..Remote Control).
 AUTOAPS       YES=APS; search function will be run automatically when the           1. Press the blue button twice (RCN..Remote     Control).
               set is switched on for the first time and stores all stations in      2. Select the menuline STANDARD.
               memory.                                                               3. Use the cursor button 4 and p to switch to STANDARD 3 or 2.
               NO=No automatic search function when the set is switched on for       4. Use the OK (M) (memory) button to store the value in memory.
               the first time.                                                       5. Return to normal TV mode by pressing the TV button.
 MODE          l=NOKIA, SALORA 2=other sets
               3=UNIVERSUM, MELECTRONIC                                              Audio IF calibration
               If the set cannot be switched on with the number buttons on the       1. Feed in test picture
               remote control, then switch the set on with the TV button and got     2. Connect oscilloscope at pin 12
               the service menu 3 (see service mode). Select the MODE setting           of TDA2545A    (stereo module).
               and alter it to correspond your set. Store the setting in memory      3. Use coil ZA61 to calibrate to
               with the OK (MI button.                                                  minimize video signal.
               Servicemenu 4                                                         Audio IF calibration (Multinorm Modul)
 NICAM         (ON/OFF)                                                              1. Go to service menu 2 (see service mode).
 LOUDNESS      (OFF=linerar frequency response)                                      2. Use cursor button A or v to select APS.
 C4 CHECK      (ON)                                                                  3. Use cursor button 4 and p to adjust to standard BG.
 CAR. MUTE     (ON/OFF)
                                                                                     4. Connect signal generator 38.9 MHz (approx. 350 mV) to test points
Adjustment Ul voltage                                                                   TP2/TP4.
1.Set the contrast and brightness to minimum.                                        5. Connect voltmeter to test point TP16.
2. Connect test point XFOl (chassis board) to ground.                                6. Use coil ZL58 to calibrate the AFC D.C. voltage to 2.5 V + 0.5 V.
3. Go to service menu 1 (see service mode).                                          7. AFC check: If the IF is increased, the AFC voltage decreases.
4. Use cursor button A or v to select Ul-adjustment.                                 8. Return to normal TV mode by pressing the TV button.
5. Adjust the Ul voltage to 109.5 V + 0.5 V (14", 17", 20") / 134.5 V f 0.5 V
   (21") / 150 V f 0.5 (25", 28") with the cursor button 4 and p at test point
   x003.
6. Use the OK(M) (memory) button to store the value in memory.
7. Remove XFOl/ground       connection again.
8. Return to normal TV mode by pressing the TV button.

AGC
1. Connect test point XFOI to ground.
2. Feed in RF signal without sound carrier with 70 dBuV on a medium UHF
   channel via the aerial input.
3. Go to service menu 1 (see service mode).
4. Use cursor button A or v to select AGC-adjustment.
5. Connect oscilloscope (bandwidth > 50 MHz) to the tuner's IF output, test
   point XL03 or XL04 and to ground XL02
6. Use cursor button 4 and)      to adjust to 400 mVpp f 50 mV with
   reference to the signal's synchronizing    peaks.
7. Use the OK (M) button to store the value in memory.
8. Remove XFOl/ground       connection again.
9. Return to normal TV mode by pressing the TV button.
4-j   I




          -
KOINZIDENZ
COINCIDENCE
COINCIDENZA
     I-
___...____.._.__._____________________________________._______---...............__._.________....
,3
r




    :1..r       .   ..I)        (I   .I




            I                             (

                    x           t


                    ii&T+  Ta
                                              -
               CA03 220n    RIB3     .k7

                 CA81         RIB2

               37       n      4k7

                                                                             12"




                                           ANA-1K?+   8C2-OUT-R
                                                          DACA-L
                                                          DACA-R



                                                       C-CACI-L
                                                       C-DACS-R

                                                         DACY-L
                                                         DACY-R




TON-ZF/IF/MF


                                           ._ _
                                           3-10




               -                                                   1
                RA00
                   lOOR                                                  w
                                                                       CA3
             ____________________________----__________________
                           MUTE




`"   RESET
9
 CA53   220n    RAW    4k7
                   U


--_(W
 CA81   220"    RIB2   4k7




                                                                 12"




                                                    5"



                                                    P    RESET




                              I
                                       NAB0
                                     YW34,O
                             SOUND      PROCESSOR
RAW      IOOR
              r
 VA73
ec800~:




          t




                  L_______________________________________---------________.
                                                                                                                                           T>   >>>
                                                                                                                             %%YY
                                                                                                                                PPrnfT YTSS
     Mono Plus 110" Stereo Chasgis
                                                                    BDIII BOlllI
                                                                       (2" 0"
                                                                    801 BDlllIl,\
                                                                      12"     0"I\




               BElJIENTEIL/




                     SF01




                                                                                                                                                              AFC   SWITCH




                                                          SCHALTNETZTEIL/SWITCH            MODE    /CIRC.ALIMENTAZIONE                                93I)m




v Waveforms      referenced to earth on TEA 2164 G pin 1 ect./ Oszillogramm-MeRpunkt        auf Masse an TEA 2164 G Pin 1 etc. bezogen./        Toutes les mesures se rapportal
Tous le oszillogrammes     se rapportant a la masse TEA 2164 G pin l./ Riferire tutti gli oscillogrammi alla massa TEA 2164 G pin 1./           rete P/ Mltta mot nltdelens mi
M&a puiser mot TEA 21646: jord, stift 1.
      C.A.F.




                                                    After   DFOZ has been      replaced, the AGC must also be recalibrated.
                                                    Nach    Austausch van       DFOZ mu!3 such die AGC neu abgeglichen werden.
                                                    Apr&s    avoir remplacC      DFOZ, AGC doit Cgalement etre r&quilibrCe.
                                                    Dopo    aver sostituito    il DFOZ B necessario equilibrare nuovamente  anche I' AGC.
                                                    AGC:    n m&Se ocks&      justetas nlr DF02 byts.




                                                                                                                                                                                      A




                                                                                          Direction arrow/ Richtungspfeil q
                                                                                          Fleche de direction/ Freccia di direzione
IT/MAINS-INSULATEWSEPARATO                OALLA RETE
________________________________________________________~~~______________________________~___________-..__-_____-------__-.~~__________________________________________--~~~_~~~__.

asurements referenced to switch-moded     power supply minus potential P / Messungen auf Schaltnetzteil-Minuspotential                      II bezogen
, les mesures se rapportant au potentiel negatif du bloc-secteur de commutation Jl / Riferire tutte le misure al potenziale                 negativo della sezione di
/ Mltta mot nltdelens minuspotential    Y
 I                SIGNAL-PROCESSOR
                  PROCESSORE    SEGNAL




                                                                                                                                         C.R.T. base bc
                                                                                                                                         Connexion tu
                                                                                                                                         5858 20 41, ..42, .




                                                                                                                           ,

                                                                                                                           I




                                                                                                                            >i
                                                                                                                           :I
                                                                                                                           I




._____________________________________~________________________~~~~~~~~~~~~~~______~___________________________________________
                                                                                                                    -_---________        I_


                        HOR.ABLENKUNG                                                                                                    `4:137
                                               $ Depending on the chassis version, these components       can either be fitted or not.
                       HOR.OEFLECTION
                       OEFLESSIONE    ORIZZ.   Diese Bauteile konnen je nach Chassisversion    bestiickt/ nicht bestijckt sein.           In standby mode, the I
                                               Suivant la version du chassis, ces composants sont mantes/ pas mantes.                     Im Standby-Betrieb lie
                                               La possibilita di montaggio di questi componenti dipende dalla versione dello chassis.     En mode stand-by les
                                                                                                                                          Net funzionamento  in
                                                                                                                      Assembly group abbreviations/ Beugruppenkurzbezeichnungen
                                                                                                                      Codiflca dei modulil DBsignations abr6g6es des sous-ensembles
                                                                                                                      Blockf6rkortningar
                                                                                                                      D = Color decoder/ Decodificatore colore/ Flrgdekoder
                                                                                                                      K k Deflessione orizzontale/ Hor. deflection/ Horisontal avlankning
                                                                                                                      S = Verticale/ Vertical
                                                                                                                      I = AF/ ZF/ HF
                                                                                                                      L =IF/MF/
                                                                                                                      F = Control unit/ Unita di comando/ Kontrollenhet
                                                                                                                      A =Audio
                                                                                                                      0   = Power supply/ Schaltnetzteil/ Circuit0 aliment. ret& N&de1
                                                                                                                      H = CRT. board/ Bildr0hrenanschlW         Colleg. cinescopio/ Bildr6rsplattan
                                                                                                                      R = Videotext! Teletext/ Televideo/ Text- TV




                             CRT. base board/ BildriihrenanschluRplatte/
                             Connexion tube image/ Collegamento cinescopio
                             5858 20 41, ..42, ..55                                                                                          STEREO CHASSIS                                    IlOO




ler be fitted or not.
!sti.ickt sein.              In standby mode, the voltages at the switch-mode power supply are approx. 30% of those applying in normal operating mode (except for U5).
5 mont6s.                    Im Standby-Betrieb liegen die Spannungen am Schaltnetzteilausgang            bei ca. 30% des Normalbetriebes    (at&r  U5L
versione    dello chassis.   En mode stand-by les tensions appliqees a la sortie du block secteur de commutation          s &vent a 30% env. du fonctionnement      normal (a part U5L
                             Net funzionamento  in stand-by, all' altezza dell' uscita del trasf. di rete le tensioni sono il30% ca. della tensioni net funzion. normale (eccetto U51



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
