        NIKKOR MF 50mm/1.8



        Fig. 1

                                                                    NO screws under
                                                                    this rubber grip




           set screw in nosepiece, revealed when lens focussed at near point
           Loosening this screw allows entire nosepiece to be unscrewed (CCW)




PDF processed with CutePDF evaluation edition www.CutePDF.com
MF 50mm/1.8 AIS After removing nose-piece

                 This entire barrel & contents moves in
