Image preview - the first page of the document

>> Download hfe_onkyo_nd-s1_en documenatation <<

Text preview - extract from the document
                                                      Important Safety Instructions .. 2
                                                      Precautions ............................... 3

                                                      Features..................................... 4

Digital Media Transport
                                                      Supplied Accessories................ 5

Instruction Manual                                    Getting to Know the ND-S1 ..... 6

                                                      Using the Remote Controller ... 7

                                                      Connecting the ND-S1.............. 8

                                                      Playing the Music and Videos on
                                                      Your iPod .................................10

                                                      Syncing Your iPod to Your PC.. 12

                                                      Playing the Music on Your PC
Thank you for purchasing an Onkyo product. Please
read this manual carefully before making any con-     Through the ND-S1.................13
nections or using this product. By following these
instructions, you'll get the best audio performance
and the most listening pleasure from your Onkyo
                                                      Troubleshooting .....................14
product. Keep this manual for future reference.

    WARNING:                                                                  WARNING                        AVIS
                                                                                  DO NOT OPEN              NE PAS OUVRIR
                                                                     The lightning flash with arrowhead symbol, within an equilateral
    CAUTION:                                                         triangle, is intended to alert the user to the presence of
                                                                     uninsulated "dangerous voltage" within the product's enclosure
    TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE              that may be of sufficient magnitude to constitute a risk of electric
    COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.               shock to persons.
    REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.                  The exclamation point within an equilateral triangle is intended
                                                                     to alert the user to the presence of important operating and
                                                                     maintenance (servicing) instructions in the literature
                                                                     accompanying the appliance.

    Important Safety Instructions
     1.   Read these instructions.                              14. Damage Requiring Service
     2.   Keep these instructions.                                  Unplug the apparatus from the wall outlet and
     3.   Heed all warnings.                                        refer servicing to qualified service personnel
     4.   Follow all instructions.                                  under the following conditions:
     5.   Do not use this apparatus near water.                     A. When the power-supply cord or plug is dam-
     6.   Clean only with dry cloth.
                                                                    B. If liquid has been spilled, or objects have
     7.   Do not block any ventilation openings. Install in
                                                                        fallen into the apparatus,
          accordance with the manufacturer's instruc-
                                                                    C. If the apparatus has been exposed to rain or
     8.   Do not install near any heat sources such as radi-        D. If the apparatus does not operate normally
          ators, heat registers, stoves, or other apparatus             by following the operating instructions.
          (including amplifiers) that produce heat.                     Adjust only those controls that are covered
     9.   Do not defeat the safety purpose of the polar-                by the operating instructions as an improper
          ized or grounding-type plug. A polarized plug                 adjustment of other controls may result in
          has two blades with one wider than the other. A               damage and will often require extensive
          grounding type plug has two blades and a third                work by a qualified technician to restore the
          grounding prong. The wide blade or the third                  apparatus to its normal operation,
          prong are provided for your safety. If the pro-           E. If the apparatus has been dropped or dam-
          vided plug does not fit into your outlet, consult             aged in any way, and
          an electrician for replacement of the obsolete            F. When the apparatus exhibits a distinct
          outlet.                                                       change in performance this indicates a need
    10.   Protect the power cord from being walked on or                for service.
          pinched particularly at plugs, convenience
          receptacles, and the point where they exit from
          the apparatus.
    11.   Only use attachments/accessories specified by
          the manufacturer.
    12.   Unplug this apparatus during lightning storms
          or when unused for long periods of time.
    13.   Refer all servicing to qualified service personnel.
          Servicing is required when the apparatus has
          been damaged in any way, such as power-sup-
          ply cord or plug is damaged, liquid has been
          spilled or objects have fallen into the apparatus,
          the apparatus has been exposed to rain or mois-
          ture, does not operate normally, or has been
