Image preview - the first page of the document

>> Download hfe_onkyo_c-7070_en documenatation <<

Text preview - extract from the document
                                                                      Getting Started ............................En-2

C-7070                                                                Connections .............................. En-13

Instruction Manual
                                                                      Basic Operation ....................... En-15

                                                                      Disc Playback ........................... En-16

                                                                      Various Playback Modes ..... En-21

                                                                      iPod / iPhone and USB
                                                                      Playback ...................................... En-24

                                                                      Setup ............................................. En-27
Thank you for purchasing an Onkyo product. Please read this
manual carefully before making any connections or using this
product. By following these instructions, you'll get the best audio
performance and the most listening pleasure from your Onkyo
product. Keep this manual for future reference.
                                                                      Miscellaneous .......................... En-29

       WARNING:                                                                 WARNING                         AVIS
                                                                               RISK OF ELECTRIC SHOCK   RISQUE DE CHOC ELECTRIQUE
       TO REDUCE THE RISK OF FIRE OR ELECTRIC                                        DO NOT OPEN              NE PAS OUVRIR
       TO RAIN OR MOISTURE.                                                  The lightning flash with arrowhead symbol, within an
                                                                             equilateral triangle, is intended to alert the user to the
                                                                             presence of uninsulated "dangerous voltage" within
       CAUTION:                                                              the product's enclosure that may be of sufficient
       TO REDUCE THE RISK OF ELECTRIC SHOCK,                                 magnitude to constitute a risk of electric shock to
       DO NOT REMOVE COVER (OR BACK). NO                                     persons.
       USER-SERVICEABLE PARTS INSIDE. REFER                                  The exclamation point within an equilateral triangle is
       SERVICING   TO   QUALIFIED    SERVICE                                 intended to alert the user to the presence of important
       PERSONNEL.                                                            operating and maintenance (servicing) instructions in
                                                                             the literature accompanying the appliance.

   Important Safety Instructions
       1.   Read these instructions.                                15. Damage Requiring Service
       2.   Keep these instructions.                                    Unplug the apparatus from the wall outlet and refer
       3.   Heed all warnings.                                          servicing to qualified service personnel under the
                                                                        following conditions:
       4.   Follow all instructions.                                    A. When the power-supply cord or plug is damaged,
       5.   Do not use this apparatus near water.                       B. If liquid has been spilled, or objects have fallen
       6.   Clean only with dry cloth.                                      into the apparatus,
       7.   Do not block any ventilation openings. Install in           C. If the apparatus has been exposed to rain or
            accordance with the manufacturer's instructions.                water,
       8.   Do not install near any heat sources such as                D. If the apparatus does not operate normally by
            radiators, heat registers, stoves, or other apparatus           following the operating instructions. Adjust only
            (including amplifiers) that produce heat.                       those controls that are covered by the operating
                                                                            instructions as an improper adjustment of other
       9.   Do not defeat the safety purpose of the polarized or            controls may result in damage and will often
            grounding-type plug. A polarized plug has two                   require extensive work by a qualified technician
            blades with one wider than the other. A grounding               to restore the apparatus to its normal operation,
            type plug has two blades and a third grounding              E. If the apparatus has been dropped or damaged in
            prong. The wide blade or the third prong are                    any way, and
            provided for your safety. If the provided plug does         F. When the apparatus exhibits a distinct change in
            not fit into your outlet, consult an electrician for            performance this indicates a need for service.
            replacement of the obsolete outlet.
                                                                    16. Object and Liquid Entry
   10.      Protect the power cord from being walked on or              Never push objects of any kind into the apparatus
            pinched particularly at plugs, convenience                  through openings as they may touch dangerous
            receptacles, and the point where they exit from the         voltage points or short-out parts that could result in
            apparatus.                                                  a fire or electric shock.
   11.      Only use attachments/accessories specified by the           The apparatus shall not be exposed to dripping or
            manufacturer.                                               splashing and no objects filled with liquids, such as
   12.      Use only with the cart, stand, PORTABLE CART WARNING        vases shall be placed on the apparatus.
            tripod, bracket, or table                                   Don't put candles or other burning objects on top of
            specified by the                                            this unit.
            manufacturer, or sold with                              17. Batteries
            the apparatus. When a cart is                               Always consider the environmental issues and
            used, use caution when                                      follow local regulations when disposing of batteries.
            moving the cart/apparatus                               18. If you install the apparatus in a built-in installation,
            combination to avoid injury S3125A                          such as a bookcase or rack, ensure that there is
            from tip-over.                                              adequate ventilation.
   13.      Unplug this apparatus during lightning storms or            Leave 20 cm (8") of free space at the top and sides
            when unused for long periods of time.                       and 10 cm (4") at the rear. The rear edge of the shelf
   14.      Refer all servicing to qualified service personnel.         or board above the apparatus shall be set 10 cm (4")
            Servicing is required when the apparatus has been           away from the rear panel or wall, creating a flue-
            damaged in any way, such as power-supply cord or            like gap for warm air to escape.
            plug is damaged, liquid has been spilled or objects
            have fallen into the apparatus, the apparatus has
            been exposed to rain or moisture, does not operate
            normally, or has been dropped.

1. Recording Copyright--Unless it's for personal use
