Image preview - the first page of the document
onkyo_dr-s2.2


>> Download onkyo_dr-s2.2 documenatation <<

Text preview - extract from the document
                                                                   DR-S2.2

                                                        Ref. No. 3721
                                                               42002
                  SERVICE MANUAL


                DVD RECEIVER
             MODEL DR-S2.2




                                                         RC-484M



              Titanium color model
UDD1N, UDT3P, UDS4P        120V AC, 60Hz
UGK3P, UGR6P               220-230V AC, 50/60Hz
UPP2P, UPA4P               230-240V AC, 50/60Hz




        SAFETY-RELATED COMPONENT
        WARNING!!
        COMPONENTS IDENTIFIED BY MARK      ON THE
        SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
        CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
        REPLACE THESE COMPONENTS WITH ONKYO
        PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
        IN THIS MANUAL.
        MAKE LEAKAGE-CURRENT OR RESISTANCE
        MEASUREMENTS TO DETERMINE THAT EXPOSED
        PARTS ARE ACCEPTABLY INSULATED FROM THE
        SUPPLY CIRCUIT BEFORE RETURNING THE
        APPLIANCE TO THE CUSTOMER.




                      Page 1

                 www.denom.com
                                                                                                                                              DR-S2.2

SPECIFICATIONS
AMPLIFIER SECTION
 Power Output (FTC)        All channels 40 watts per channel min.             LINE (VIDEO 1, VIDEO 2/CDR/PC, TV/LINE, TAPE/MD/HD)
                           RMS. into 6 ohms two channel driven,                                                         200 mV/50 kohms
                           1,000 Hz with no more than 5 % total               Composite (VIDEO 1, VIDEO 2/CDR/PC) 1 Vp-p, 75 ohms
                           harmonic distortion.                               S-VIDEO (VIDEO 1, VIDEO 2/CDR/PC) Y: 1 Vp-p, 75 ohms
Continuous power output (DIN)                                                                                           C: 0.28 Vp-p, 75 ohms
                           All channels 30 watts per channel min.         Output Level and Impedance
                           RMS. into 6 ohms two channel driven,               DIGITAL OUTPUT (OPT)
