                                         CONFIDENTIAL

                                                                                        Technical Tip
18 Park Way, Upper Saddle River, NJ 07458
                                          Date: February 22, 2006
 _____________________________________________________________

 Model: HTR-330, HTR-430, HTR-530, TX-SR303, TX-SR503, TX-SR573, TX-
 SR603X

 Subject: Noise in surround channels.

 Symptom: If the customer complaint states "noise in the surround channels". Perform
 the following update:

 Solution: Add a 220uf/63V electrolytic capacitor* to the Display PCB as shown:




 ______________________________________________________________________________________
                              CONFIDENTIALITY NOTICE:
 This document and the information it contains is intended for the exclusive use of Authorized ONKYO Service Centers and their
 employees. This document may contain information that is privileged, confidential and exempt from disclosure under applicable law
 and terms of the ONKYO Service Agreement. Any dissemination, distribution or copying of this document and the information it
 contains is strictly prohibited.
                                                     Display board




*Secure the 220uF/63V capacitor to the Display board with Sony bond.

Parts:

              Ref#                    Description                                       Part Number
              N/A                 220uf/63V electrolytic                                 394672217
                                        capacitor

______________________________________________________________________________________
                             CONFIDENTIALITY NOTICE:
This document and the information it contains is intended for the exclusive use of Authorized ONKYO Service Centers and their
employees. This document may contain information that is privileged, confidential and exempt from disclosure under applicable law
and terms of the ONKYO Service Agreement. Any dissemination, distribution or copying of this document and the information it
contains is strictly prohibited.
