Image preview - the first page of the document
hfe_onkyo_ht-s3500_ht-r391_service_en


>> Download hfe_onkyo_ht-s3500_ht-r391_service_en documenatation <<

Text preview - extract from the document
                                                                                                                              HT-S3500

                                                                                                                     Ref. No. 4365
                                                                                                                           022012




                                    5.1CH HOME THEATER SYSTEM
                                            MODEL HT-S3500(B)
a   Indoor FM antenna                   a                     b                        c                     d
b   AM loop antenna
c   Remote controller and two
    batteries (AA/R6)
d   Power cord (Brazilian models)       e
    (Plug type varies from country to
    country.)
e   Speaker Package                                      (White) (Red)                      (Green)                 (Blue) (Gray)
                                              Front     Speaker cables       Center   Speaker cable     Surround    Speaker cables
*1 Configuration of the rubber              speakers      10 ft. (3.0 m)    speaker    10 ft. (3.0 m)   speakers     26 ft. (8.0 m)
   stoppers may be different from           SKF-391                         SKC-391/C                   SKR-391
   the figure, such as being 2 sheets
   instead of 1 sheet, but the total
   number will be same.


                                                                                              (Purple)
                                             20 rubber stoppers*1          Subwoofer   Speaker cable 4 floor pads
                                              (For Front/Center/           SKW-391      10 ft. (3.0 m)
                                             Surround speakers)

                                                  (Asian models)                   (North American and Brazilian models)




                                                                               HT-R391                                       RC-799M
        Black model
     B MMQ          230V AC, 50Hz                      HT-R391(B)MMQ + SKF-391(B)MC + SKC-391C(B)MQ + SKR-391(B)MC + SKW-391(B)MQ
     B MMK          230V AC, 500Hz                     HT-R391(B)MMK + SKF-391(B)MC + SKC-391C(B)MQ + SKR-391(B)MC + SKW-391(B)MQ
     B MDC          220-240V AC, 50/60Hz               HT-R391(B)MDC + SKF-391(B)MC + SKC-391(B)MC + SKR-391(B)MC + SKW-391(B)MC
     B MDS          230V AC, 50Hz                      HT-R391(B)MDS + SKF-391(B)MC + SKC-391(B)MC + SKR-391(B)MC + SKW-391(B)MC



    SAFETY-RELATED COMPONENT WARNING!!
    COMPONENTS IDENTIFIED BY MARK              ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK
    OF FIRE AND ELECTRIC SHOCK.
    REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL.
    MAKE LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS TO DETERMINE THAT EXPOSED ARTS ARE ACCEPTABLY
    INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.
                                                                          HT-R391

                                                                    Ref. No. 4380
                                                                          022012




           AV RECEIVER
    MODEL HT-R391(B)
                North American and Brazilian models ---> "DIMMER"
                Asian models ---> "RT/ PTY/ TP"




                                                                     RC-799M
Black model for HT-S3500
 B MDC, B MDS      120V AC, 60Hz
 B MMK, B MMQ      220-240V AC, 50/60Hz
                                                                                                                                   HT-R391


SERVICE PROCEDURE-1

 1. Replacing the fuses

                    This symbol located near the fuse indicates that the
    fuse used is slow operating type, For continued protection against
    fire hazard, replace with same type fuse, For fuse rating, refer to
    the marking adjacent to the symbol.

                  Ce symbole indique que le fusible utilise est e lent.
    Pour une protection permanente, n'utiliser que des fusibles de meme
    type. Ce demier est indique la qu le present symbol est apposre.
      REF NO.       PART NAME          DESCRIPTION             PART NO.      REMARKS
      F6901         FUSE               8A-T/UL-ST2             252261GR       !
      F6902         FUSE               8A-T/UL-ST2             252261GR       !
      F901          FUSE               8A-UL/T-233             252329GR       !
      F901 or       FUSE               8A-T/UL-ST2             252261GR       !
      F901          FUSE               4A-SE-EAK               252077GR       !
      F901 or       FUSE               4A-SE-TL250V            252277GR       !
      F9001         FUSE               5A-UL-125V              252385T        !

 2. Safety check out
  (U.S.A. model only)
  After correcting the original service problem, perform the following safety check before releasing the unit to the customer.
  Leakage current Check
  Measure the leakage current to a known earth ground (water pipe or conduct etc.) by connecting a leakage current
  tester between the earth ground and exposed metal parts of the unit (input/output ground terminals, screw heads or metal overlays etc.).
  Plug the power supply cord directly into a 120Vac 60Hz wall socket and turn ON/STANDBY button on.
  Any current measured must not exceed 0.5mA.

 3. To initialize the unit
  1. Press ON/STANDBY button while pressing down VCR/DVR button when the unit is POWER ON, then the FL displays
    "CLEAR", and turn to STAND-BY.
     Preset memory and each mode stored in the memory, are initialized and will return to the factory settings.

                       Clear                        Stand-by

  2. Remove power cord from wall outlet.


            ON/STANDBY               VCR/DVR
                                                                                                HT-R391


SERVICE PROCEDURE-2

 4. To check version of each Firmware
 1. Press ON/STANDBY (Power On)

 2. Press DISPLAY + ON/STANDBY.
                  e.g.
                                                     Version of Main Microprocessor displayed
                           M:1.00/11Z22A L U         only for 3 seconds.


 3. Press   (Tone) ---> Forward

   Press    (Tone) ---> Reversed.
                                                            Version displayed
                                                            only for 3 seconds.
                  (TONE)
                  e.g.
                           M:1.00/11Z22A L U          Main Microprocessor

                                            (TONE)
                  (TONE)
                   e.g.
                           D:1.00/11Z05a L            DSP

                                            (TONE)
                  (TONE)
                   e.g.
                           O:1.00/11Z02A L            HDMI/Video Microprocessor

                                            (TONE)


 4. Press ON/STANDBY (Power Off).

             ON/STANDBY       (TONE)   (TONE)         DISPLAY
                                                                   TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-1
AUDIO DEBUG MODE-1/5
 The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode.
 This information will help to analysing digital audio no sound trouble.

 To set in Debug mode
 1. Press and hold down DISPLAY button, then press ON/STANDBY button.

                   e.g.                                           The version number of microprocessor is displayed
                              M1.06/12417A E                      only for 3 seconds.


 2. Press + (TONE) button while the version number of microprocessor is displayed.
                   e.g.                                           The version number of DSP is displayed
                              D1.05/12327A E A                    only for 3 seconds.

 3. Press DISPLAY button while the version number of DSP is displayed.
                   e.g.                                                AUDIO dubug mode
                              4D48K1N 0FF P o 0                        The status of DSP and DIR etc
                                                                       will be displayed.
 11. Press DISPLAY button.
                 e.g.
                                                               Exit



                 ON/STANDBY      + (TONE)
                                                                 DISPLAY
                                                                     TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-2
AUDIO DEBUG MODE-2/5
 Contents of Display
                                                       FL Display




                                                     Display area

       e.g.
                  0A0002:__:00__

Number of            1       2       3   4       5      6        7         8   9    10   11       12    13    14     15
digits




Number of        1       2       3           4               5         6            7         8         9    10    11
Parameters

      1. DIR INPUT LOCK/UNLOCK                   5. DIR DETECT TYPE                      9. DSP DETECT FORMAT
            E:UNLOCK                                 0:Analog                              P:PCM(Analog)
            :LOCK                                    1:PCM                                 D:Dolby Digital
                                                     2:Not PCM                             d:DTS
      2. DIR INPUT RX                                3:Data                                A:AAC
                                                     4:DTS CD(Not used)                    d:DTS
            0:None
                                                     5:Multich                             A:AAC
            1:COAX1
                                                     6:Not Decided                         S:DSD
            2:COAX2
                                                                                           p:DolbyDigital+
            3:OPT1
                                                                                           T:TrueHD
            4:OPT2                               6. CODEC CLOCK MODE                       H:DTSHD High Resolution
            5:FRONT                                  N:Normal                              M:DTSHD MaterAudio
            8:HDMI1                                  U:Up Sampling                         ?:UNKNOWN
            9:HDMI2                                  H:High Sampling(Double Rate)
                                                     D:Down Smapling
                                                                                         10. DSP DECODE OK
      3. DIR/ADC,FIX MODE                            Q:Quad Rate
                                                                                           o:OK
            D:Digital(SPDIF)                                                               x:NG
            A:Analog                             7. DSP PORT
            M:AnalogMultich                          bit0:NIC                            11. Mute
            p:PCM FIXED                              bit1:DEC
            d:DTS FIXED                                                                    1:Selector
                                                     bit2:BUSY                             2:Effector
                                                     bit3:EXEC WAIT                        4:DSP
      4. Sampling Freq,Emphasis
                                                     Refer to "DEBUG MODE-3"               8:DIR
            32K: 32 kHz w/o Emphasis
                                                     Description of the DSP PORT
            44K: 44.1kHz w/o Emphasis
                                                     (NIC/DEC/SPI Busy/Exec wait)
            48K: 48 kHz w/o Emphasis
            64K: 64 kHz
            88K: 88.2kHz                         8. DSP SEQUENCE
            96K: 96 kHz                              00-FE:NotFree
            176:176.4kHz                             2D:Mute Control
            192:192 kHz                              FF:Free
            32e: 32 kHz w Emphasis
            44e: 44.1kHz w Emphasis                  Refer to "DEBUG MODE-4, -5"
            48e: 48 kHz w Emphasis                   Description of the
                                                     DSP Sequence
                                                                     TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-3
AUDIO DEBUG MODE-3/5
 Description of the DSP PORT(NIC/DEC/SPI Busy/Exec wait)


 Number of             1       2       3        4        5    6         7       8   9      10     11       12   13      14        15
 digits




  Number of        1       2       3                 4              5       6             7            8        9     10     11
  Parameters




Display
contents       Internal state              Inferred state

   0                                       Stable state

   1       NIC                             If the stop remains "1" is indicated, it is possible that there is an abnormality in
                                           the connection between the microcomputer and the NIC.
   2       DEC                             Please check if the input signal Dolby / DTS / AAC / PCM from Coax or OPT.
                                           If the stop remains "2" is indicated, it is possible that there is an abnormality
                                           in the connection between the DIR and the DSP.
                                           There is a case of "2" for the state to stop or pause playback equipment.
                                           And it is normal.

   3       NIC+DEC                         If the stop remains "3" is indicated, it is possible that there is an abnormality in
                                           the connection between the microcomputer and the NIC.
   4       SPI Busy
                                           If the stop in these numbers, it is possible that there is an abnormality in
                                           the connection between the DSP and the microcomputer.
   5       SPI Busy + NIC

   6       SPI Busy + DEC

   7       SPI Busy + NIC + DEC

   8       Exec wait

   9       Exec wait + NIC                 If you stop at these numbers, please check the DSP Sequence.

   A       Exec wait + DEC

   B       Exec wait + NIC+DEC

   C       Exec wait + SPI Busy
           Exec wait + SPI Busy
   D       + NIC
           Exec wait + SPI Busy
   E       + DEC
           Exec wait + SPI Busy
   F       + NIC + Dec
                                                               TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-4
AUDIO DEBUG MODE-4/5
 Description of the DSP Sequence(1/2)


 Number of            1       2       3   4         5   6         7       8   9     10      11       12   13     14     15
 digits




  Number of       1       2       3            4              5       6            7             8        9     10     11
  Parameters



 Display
                 Inferred state                          Possible Causes
 contents
 Stop at "03" Have not been able to communicate         1.There is a problem with the connection between the FlashROM and
 is indicated. between the microcontroller and           the DSP, and the SDRAM.
               the DSP.                                 2.Power is not supplied to the DSP.
                                                        3.Operation clock is not input to the DSP.
                                                        4.Reset port of the DSP is not connected.
                                                        5.There is a problem with the line of communication between the
                                                          microcontroller and DSP.
                                                        6.DSP is broken or Microcomputer.
                                                        7.Program has not been successfully written to the Flash ROM. Or the
                                                          program is not written.
                                                        8.Communication port (such as DIR) other devices are connected to t
                                                          he SPI mode is broken short. Terminals are short-circuited.

 Stop at "05"    Have not been able to write from       1.Program is not written correctly to Flash ROM.
 is indicated.   the boot loader of the DSP.            2.DSPSDO line of microcomputer is interrupted somewhere.
                                                        3.There is a problem with the FlashROM (or SDRAM) of DSP.
                                                        4.DSP is broken or Microcomputer.
                                                        5.Upper address bus of Flash ROM is not connected properly.


 Stop at "08"    While running the boot loader of DSP, 1.SDRAM is broken or Flash ROM.
 is indicated.   the main program is not running.      2.Upper address bus of Flash ROM is not connected properly.
                                                       3.Program is not written correctly to Flash ROM.
                                                       4.There is a possibility that the power is turned off during
                                                         the S / PDIF Update.

 Stop at         Main program of DSP is not working     1.SDRAM is broken or Flash ROM.
 "09 - 0C"       properly.                              2.Upper address bus of Flash ROM is not connected properly.
 is indicated.                                          3.Program is not written correctly to Flash ROM.
                                                        4.There is a possibility that the power is turned off during
                                                          the S / PDIF Update.


 Stop at "17"    There is a possibility that the power is Solution :
 is indicated.   turned off during the S / PDIF Update. Hold down the VCR/ DVR when the power is turned on, press the
                                                          On/Standby key. (Clear)
                                                          When out of the state of S / PDIF Update, please press the
                                                          On/Standby key.
                                                               TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-5
AUDIO DEBUG MODE-5/5
 Description of the DSP Sequence(2/2)


 Number of            1       2       3     4       5   6         7       8   9     10      11       12   13      14     15
 digits




  Number of       1       2       3             4             5       6            7             8        9     10      11
  Parameters



 Display
                 Inferred state                         Possible Causes
 contents

                 Main program of DSP is not working     1.SDRAM(or Flash ROM) is broken.
                 properly.                              2.Upper address bus of Flash ROM is not connected properly.
                                                        3.Program is not written correctly to Flash ROM.
                                                        4.Operation clock to the DSP is not a predetermined value.
 Stop at "21", to return to the
 previous display after a while.
 Format display indicator flashes.

 Stop at         main program of DSP is not working     1.SDRAM(or Flash ROM) is broken.
 "22-24"         properly.                              2.Upper address bus of Flash ROM is not connected properly.
 is indicated.   The audio signal is not input.         3.Program is not written correctly to Flash ROM.
                                                        4.Operation clock to the DSP is not a predetermined value.
                                                        5.Audio clock to the DSP is not a predetermined value.

 Stop at         main program of DSP is not working     1.SDRAM(or Flash ROM) is broken.
 "30-33"         properly.                              2.Upper address bus of Flash ROM is not connected properly.
 is indicated.   The audio signal is not input.         3.Program is not written correctly to Flash ROM.

 Stop at         DSP settings has failed.               1.SDRAM(or Flash ROM) is broken.
 "26-2F"                                                2.Upper address bus of Flash ROM is not connected properly.
 is indicated.                                          3.Program is not written correctly to Flash ROM.

 Stop at "FF" The DSP is functioning properly.          All settings are completed, DSP has started normal operation.
 is indicated.

                 There is no sound even though it is        Refer to "DEBUG MODE-3"
                 the display of "FF".                       Description of the DSP PORT
                                                            (NIC/DEC/SPI Busy/Exec wait)
                                                                                      TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-6
HDMI DEBUG MODE-1/6

  HDMI-related operations can be checked to some extent by displaying HDMI debug mode.

  To enter this mode
  Hold down DISPLAY button for 3 seconds. Information display will last for about 8 seconds.




  Content of Display




             1           2           3       4       5        6         7         8   9       10   11       12       13       14

    Resolution display
       Input resolution                                                               Output resolution

         10 80 i / 6 0                                                                                           10 80 i / 6 0
         1       2   3       4   5       6   7   8   9   10   11   12   13   14           1    2   3    4   5    6   7    8   9    10   11   12   13   14



       List of standard resolution

                     4 8 0 i / 6 0                                  # 5 7 6 i / 5 0                                  5 7 6 p 2 0 0
                     4 8 0 p / 6 0                                  # 5 7 6 p / 5 0                                  5 7 6 i 2 0 0
             1 0 8 0 i / 6 0                                        # 2 8 8 p / 5 0                                  4 8 0 p / 6 0
                     7 2 0 p / 6 0                                  1 0 8 0 p / 2 4                                  4 8 0 p 2 4 0
             1 0 8 0 p / 6 0                                        1 0 8 0 p / 2 5                                  4 8 0 i 2 4 0
                     2 4 0 p / 6 0                                  1 0 8 0 p / 3 0                              * 4 8 0 p / 6 0
             # 4 8 0 i / 6 0                                                  VGA                                * 5 7 6 p / 5 0
             # 4 8 0 p / 6 0                                        1 0 8 0 i 1 0 0                                  7 2 0 p / 2 4
             # 2 4 0 p / 6 0                                                7 2 0 p 1 0 0                            7 2 0 p / 2 5
                     5 7 6 i / 5 0                                          5 7 6 p 1 0 0                            7 2 0 p / 3 0
                     5 7 6 p / 5 0                                          5 7 6 i 1 0 0
             1 0 8 0 i / 5 0                                        1 0 8 0 i 1 2 0
                     7 2 0 p / 5 0                                          7 2 0 p 1 2 0
             1 0 8 0 p / 5 0                                                4 8 0 p 1 2 0
                     2 8 8 p / 5 0                                          4 8 0 i 1 2 0
                                                              TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-7
HDMI DEBUG MODE-2/6
Display of Input resolution
    DVI input signal
                                                       4 80 I / 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14


                                                       4 80 P/ 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                           i / p will be capitalized.
    VGA input signal
                                                                  VGA
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                       Display the "        " in column 1
    No input
                                                 Un k n own
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14


Display of Output resolution
   For a video processor        Via VSP                                   1 0 8 0 i / 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                  Display the "           " in column 4

                                VSP skip
                                                                          1 0 8 0 i / 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14

   DVI input signal
                                                                               4 80 I / 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14



                                                                               4 80 P/ 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                                                   i / p will be capitalized.
   VGA input signal
                                                                               4 80 p/ 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                  Display the "           " in column 5
   RSEN is OFF
                                                                               4 80 p/ 6 0
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                                                               Display the "             " in column 14
   EDID_READ is NG
                                                                               4 80 p/ 6 0#
                                                 1     2      3   4   5    6   7     8   9    10    11    12   13   14
                                                                                                   Display the " # " in column 14
   Resolution Error
                                                                               4 80 p/ 6 0x
                                                 1     2     3    4   5    6   7     8   9    10    11    12   13   14
                                                                                               Display the " x " in column 14
   No output
   (Signal output destination                                         - - - - - -
   can not be found.)                            1     2      3   4   5    6   7     8   9    10    11    12   13   14

   Hot-plug of Sink equipment
   can not be detected.                                                              OFF
                                                  1    2      3   4   5    6   7     8    9   10     11   12   13   14
                                                                                                                     TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-8
HDMI DEBUG MODE-3/6

 4K Upscaling
  Display of input resolution

              1 0 8 0 i / 6 0
               1   2   3   4       5       6       7       8       9       10       11       12       13        14


  Display of Output resolution

                                   x                                        p /
               1   2   3   4       5       6       7       8       9       10       11       12       13        14


                                                                                                                      If the three-digit numbers are refrate
                                                                                    11       12       13        14


  List of resolution

             3 8 40 x 2 1 60 p / 30
              1    2   3   4       5       6       7       8       9       10       11       12       13    14


             3 8 40 x 2 1 60 p / 25
              1    2   3   4       5       6       7       8       9       10       11       12       13    14


             3 8 40 x 2 1 60 p / 24
              1    2   3   4       5       6       7       8       9       10       11       12       13    14


             4 0 96 x 2 1 60 p / 24
              1    2   3   4       5       6       7       8       9       10       11       12       13    14




   Resolution Error            3 8 40 x 2 1 60 p / 30x
                               1       2       3       4       5       6        7        8        9        10    11   12   13   14



   EDID_READ_NG                3 8 40 x 2 1 60 p / 30#
                               1       2       3       4       5       6        7        8        9        10    11   12   13   14
                                                                  TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-9
HDMI DEBUG MODE-4/6

                 Resolution display   1 0 8 0 p/ 24                         ( 3 D)
                                      1   2   3   4   5   6   7     8   9   10   11   12    13   14



                 Status Display       HDM I               444               36 b i t
                                      1   2   3   4   5   6   7     8   9   10   11   12    13   14


                 3D format
                                      F r ame                 P ac k i ng
                                      1   2   3   4   5   6   7     8   9   10   11   12    13   14


                 INPUT/OUTPUT         I N :                         OUT :
                                      1   2   3   4   5   6   7     8   9   10   11   12    13   14

Display of Input resolution
   RSEN OFF
                                              1 0 80 p / 24                            ( 3 D)
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14
                                                                                       Display the "            " in column 14
   EDID READ NG
                                              H DM I                44 4# 3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14
                                                                  Display the " # " in column 9
   Resolution Error
                                              1 0 80 p / 24                            ( 3 D) x
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14
                                                                                           Display the " x " in column 13

Status
   Input Mode        HDMI input
                                              H DM I                44 4              3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14

                     DVI input
                                              DV I                  44 4              3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14

                     No input
                                              - - -                 44 4              3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14

   Input Color       RGB                      H DM I               RGB                3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14


                     422
                                              H DM I                42 2              3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14

                     444
                                              H DM I               44 4               3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14

   Deep Color
                     24bit                    H DM I               RGB                2 4 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14


                     30bit                    H DM I               RGB                3 0 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14


                     36bit                    H DM I               RGB                3 6 b i t
                                              1   2   3   4   5     6   7   8    9    10    11   12   13   14
                                                                                 TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-10
HDMI DEBUG MODE-5/6

3D format
   Frame Packing
                                            F r a me _P a c k i n g _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   Field alternative
                                            F _a l t e r na t i v e _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   Line alternative
                                            L _a l t e r na t i v e _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14


   Side-by-Side(Full)                       S i d eb y Si d e ( F) _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   L+depth
                                            L               d ep t h __ _ __ _ _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   L+depth + graphics
                                            L               d ep t h g r a ph i c
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   Side by Side(Harf)
                                            S i d eb y Si d e ( H) _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   Top and Bottom
                                            T o p - a n d - B o t t om
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14

   unknown
                                            UN K N OWN _ _ _ _ _ _ _
                                            1       2       3       4       5        6        7        8        9        10   11   12   13   14




INPUT/ OUTPUT

                        I N :                                   OU T :
                        1   2   3   4   5       6       7       8       9       10       11       12       13       14
                                                                                            TX-SR313/ HT-R358/391/558/591/ HT-RC430


DEBUG MODE-11
HDMI DEBUG MODE-6/6
PC resolution
                      Input Resolution                  1 0 2 4x                                         76 8 p/ 6 0
                                                        1       2       3       4       5       6        7        8        9        10        11       12       13       14



                      Output Resolution                 1 0 2 4x                                         76 8 p/ 6 0
                                                        1       2       3       4       5       6        7        8        9        10        11       12       13       14

 Display of Input resolution

                                                                            x                                          p /
                                            1       2       3       4       5       6       7        8        9       10       11        12        13       14

                           Horizontal resolution                            Vertical resolution                                      Referat

     DVI input                        Display uppercase
                                      P/I
                                                                                            1 0 24 x                                               768P/ 6 0
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


     HDMI input                       Display lowercase
                                      p/i
                                                                                            1 0 24 x                                               768p / 6 0
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14

     Three-digit numbers
     are Referat                                                                            1 0 24 x                                               768P12 0
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14

     No input
                                                                                            U N K N OW N
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


 Display of Output resolution

                                                                            x                                         p /
                                            1       2       3       4       5       6       7        8        9       10       11        12        13       14

                           Horizontal resolution                            Vertical resolution                                      Referat

     DVI output                       Display uppercase
                                      P/I
                                                                                            1 0 24 x                                                768P/ 6 0
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


     HDMI output                      Display lowercase
                                      p/i
                                                                                            1 0 24 x                                                768p / 6 0
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


     Display"-----"                                                                                                                       - - - - -
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14

     Three-digit numbers
     are Referat
                                                                                            1 0 24 x                                                768P12 0
                                                                                            1        2        3        4        5         6         7        8       9        10   11   12   13   14

     EDID READ NG                     Display the " # " in
                                      column 13                                             1 0 24 x                                                768P/ 6 0 #
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


     Resolution through               Display the " x " in
                                      column 13                                             1 0 24 x                                                768P/ 6 0x
                                                                                            1        2        3        4        5        6         7        8        9        10   11   12   13   14


 INPUT/ OUTPUT

                              I N :                                             OU T :
                              1   2     3       4       5       6       7       8       9       10       11       12       13       14
                                              TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440


OPERATION CHECK-1
1.OPERATION CHECK(1/2)
1-1. OPERATIONS OF VOLTAGE-DETECTION PROTECTORS.
    See "OPERATION CHECK-3, -5" for TEST MODE operation.
    NOTE: Don't connect load nor short speaker terminals.
 a. Change the state to "TEST-4-21".
 b. It tests by being automatic in order of TEST4-21(FL+)  22(FR-)  23(C+)  24(SL-)
     25(SR+)  ( 26(SBL-)  27(SBR+) ). It becomes the display of "TEST-4-35."
 c. It will complete, if displayed on FL TUBE as "TEST-4-35."
 d. Check operation of voltage-detection of subwoofer channnel. (HT-R391/358 only)
    Change the state to "TEST-1-00".
    The speaker relay is OFF immediately after D.C. +1.5v 3v is put at J4082 J4090 to check SW.
    The same as above when D.C. -1.5v 3v is put at each place.

   NOTE1: Limit time to apply voltage is 0.5-1.0 seconds each channel.
          When protection operation does not occur at once, try several times.
   NOTE2: Don't connect load nor short speaker terminals.
   NOTE3: The relay shall recover in one second in "TEST-1-00". So it shall not be hold OFF.

1-2. OPERATIONS OF CURRENT-DETECTION PROTECTORS
    See "OPERATION CHECK-3, -4" for TEST MODE operation.
  a. Change the state to "TEST-4-35".
     Even if you connect 3-ohm load for every channel of L, R, C, SL, SR, SBL,SBR and SWch, a relay should not cut off.
     If 1-ohm load is connected for every channel of L, R, C, SL, SR,SBL,SBR and SWch, a relay should hold the state of ON.

1-3. CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION (Applied to MPP/MPB type)
  a. Input 98MHz,30dB signal modurated with RDS data.
  b. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds instead of the frequency.

1-4. CONFIRMATION OF HEAD PHONE OPERATION.
   Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted into the PHONES jack.

1-5. COMFIRMATION OF USB(Except of HT-R358)
    See "OPERATION CHECK-3, -4" for TEST MODE operation.
 a. Connect ipod to AVR USB port.
 b. When set to TEST-3-10, confirm that the display of AVR change "connecting" to "press Push [MODE] button ...." or "iPod"
    after few seconds.
    The following iPod models can be used for inspection.(The above-mentioned operation is not done excluding the following items.)
       iPod classic, 3G nano, 4G nano, 5G nano

1-6. CONFIRMATION OF OUTPUT SENSOR AND THERMAL SENSER.
    See "OPERATION CHECK-3, -5" for TEST MODE operation.
 a. Set the TEST MODE to "TEST-4-36" and "TEST-4-37".
    After light "FM STEREO" on FL display, the relays RL691/692 is OFF and "FM STEREO"is off .(TEST4-37 is only for HT-R591.)
 b. Push ON/Standby button while pushing down DISPLAY button to display CPU PROGRAM version.
    Push TONE button while displaying CPU PROGRAM version to display value of temparature sensor.
    Confirm outside temperature



◦ Jabse Service Manual Search 2024 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
