Image preview - the first page of the document



>> Download hfe_onkyo_integra_dpc-7-4_service_en documenatation <<

Text preview - extract from the document

                                                           DPC-7.4

                                                   Ref. No. 3765

          SERVICE MANUAL                            Aug, 2003




         DVD CHANGER
      MODEL DPC-7.4




                                                RC-543DV
              Black model
     BMDD         120V AC, 60Hz
     BMPA         230-240V AC, 50Hz




SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK      ON THE
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
                                                                                                                            DPC-7.4

SPECIFICATION



  Video system                                                   Standard NTSC (U.S. model), PAL/AUTO (Australian model)
  Region code                                                    1 (U.S. model), 4 (Australian model)
  Laser                                                          Semiconductor laser, wavelength 650 nm (DVD), 780 nm (CD)
                                                                 4 Hz - 22 kHz @ 48 kHz sampling rate
                                 DVD linear audio
  Frequency response                                             4 Hz - 44 kHz @ 96 kHz sampling rate
                                 CD audio                        4 Hz - 20 kHz
  Signal-to-noise ratio (digital audio)                          100 dB
  Audio dynamic range (digital audio)                            93 dB
  Harmonic distortion (digital audio)                            0.006%
  Wow and flutter                                                Below measurable level (
