Image preview - the first page of the document



>> Download hfe_onkyo_k-505tx_service_en documenatation <<

Text preview - extract from the document

                                                                                                             K-505TX



                                                                                                    Ref. No . 3675
                      R            SERVICE MANUAL                                                      052001


           STEREO
        CASETTE DECK
        MODEL K-505TX

                    STEREO CASSETTE TAPE DECK
                                                                                        DOLBY NR



                                                                                        REV. MODE
                                        CASSETTE LOADING MECHANISM


     STANDBY / ON
                      ALBUM                                               REC LEVEL




      STANDBY
                                                                        COUNTER RESET




                       FADE                                                             K- 505X




                Silver models
                      SUPP,SUPT                                      230V AC,50Hz

                              SUDT                                   120V AC,60Hz



SAFETY-RELATED COMPONENT WARNING!!


   COMPONENTS IDENTIFIED BY MARK         ON THE
   SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
   CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
   REPLACE THESE COMPONENTS WITH ONKYO
   PARTS WHOSE PART NUMBER APPEAR AS SHOWN
   IN THIS MANUAL.


   MAKE LEAKAGE CURRENT OR RESISTANCE
   MEASUREMENTS TO DETERMINE THAT EXPOSED
   PARTS ARE ACCEPTABLY INSULATED FROM THE
   SUPPLY CIRCUIT BEFORE RETURNING THE
   APPLIANCE TO THE CUSTOMER.
                                                                                                      K-505TX



SPECIFICATIONS

Track format                                        Power supply rating
      4-tracks, 2-channels                               AC 230-240 V, 50 Hz
Erasing system                                           AC 120 V, 60 Hz
      AC erase                                      Power consumption
Tape speed                                              12 W (230-240 V, 50 Hz)
                                                        14 W (120 V, 60 Hz)
     4.8 cm/sec.
Wow and flutter                                     Dimensions
      0.1 % (WRMS)                                       205 mm
