Image preview - the first page of the document

>> Download Manual_LS3100_En documenatation <<

Text preview - extract from the document
Living Speaker System
                                                               Before Use .........................2

Sound System Controller (LAP-301)                              Connections ....................14
Front Speakers (SLM-301)
Wireless Subwoofer (SLW-301)

                                                               Operations .......................17

Instruction Manual
                                                               Useful Function...............21


Thank you for purchasing an Onkyo product. Please read this
manual thoroughly before making connections and plugging
in your new Onkyo product.
Following the instructions in this manual will enable you to
obtain optimum performance and listening enjoyment from
your new product.
Please retain this manual for future reference.

                                                                                                                          Before Use

          WARNING:                                                            WARNING                         AVIS
                                                                             RISK OF ELECTRIC SHOCK   RISQUE DE CHOC ELECTRIQUE
          TO REDUCE THE RISK OF FIRE OR ELECTRIC                                   DO NOT OPEN              NE PAS OUVRIR
          TO RAIN OR MOISTURE.                                             The lightning flash with arrowhead symbol, within an
                                                                           equilateral triangle, is intended to alert the user to the
                                                                           presence of uninsulated "dangerous voltage" within
          CAUTION:                                                         the product's enclosure that may be of sufficient
          TO REDUCE THE RISK OF ELECTRIC SHOCK,                            magnitude to constitute a risk of electric shock to
          DO NOT REMOVE COVER (OR BACK). NO                                persons.
          USER-SERVICEABLE PARTS INSIDE. REFER                             The exclamation point within an equilateral triangle is
          SERVICING   TO   QUALIFIED    SERVICE                            intended to alert the user to the presence of important
          PERSONNEL.                                                       operating and maintenance (servicing) instructions in
                                                                           the literature accompanying the appliance.

     Important Safety Instructions
     1.    Read these instructions.                                14. Refer all servicing to qualified service
     2.    Keep these instructions.                                    personnel. Servicing is required when the
     3.    Heed all warnings.                                          apparatus has been damaged in any way, such as
     4.    Follow all instructions.                                    power-supply cord or plug is damaged, liquid
     5.    Do not use this apparatus near water.                       has been spilled or objects have fallen into the
     6.    Clean only with dry cloth.                                  apparatus, the apparatus has been exposed to
     7.    Do not block any ventilation openings. Install in           rain or moisture, does not operate normally, or
           accordance with the manufacturer's instructions.            has been dropped.
     8.    Do not install near any heat sources such as            15. Damage Requiring Service
           radiators, heat registers, stoves, or other                 Unplug the apparatus from the wall outlet and
           apparatus (including amplifiers) that produce               refer servicing to qualified service personnel
           heat.                                                       under the following conditions:
     9.    Do not defeat the safety purpose of the polarized           A. When the power-supply cord or plug is
           or grounding-type plug. A polarized plug has                     damaged,
           two blades with one wider than the other. A                 B. If liquid has been spilled, or objects have
           grounding type plug has two blades and a third                   fallen into the apparatus,
           grounding prong. The wide blade or the third                C. If the apparatus has been exposed to rain or
           prong are provided for your safety. If the                       water,
           provided plug does not fit into your outlet,                D. If the apparatus does not operate normally
           consult an electrician for replacement of the                    by following the operating instructions.
           obsolete outlet.                                                 Adjust only those controls that are covered
     10.   Protect the power cord from being walked on or                   by the operating instructions as an improper
           pinched particularly at plugs, convenience                       adjustment of other controls may result in
           receptacles, and the point where they exit from                  damage and will often require extensive
           the apparatus.                                                   work by a qualified technician to restore the
     11.   Only use attachments/accessories specified by                    apparatus to its normal operation,
           the manufacturer.                                           E. If the apparatus has been dropped or
     12.   Use only with the cart,         PORTABLE CART WARNING            damaged in any way, and
           stand, tripod, bracket, or                                  F. When the apparatus exhibits a distinct
           table specified by the                                           change in performance this indicates a need
           manufacturer, or sold                                            for service.
           with the apparatus. When
           a cart is used, use caution
           when moving the                S3125A

           cart/apparatus combination to avoid injury from
     13.   Unplug this apparatus during lightning storms or
En         when unused for long periods of time.

16. Object and Liquid Entry                              Precautions
    Never push objects of any kind into the
    apparatus through openings as they may touch         1.   Recording Copyright--Unless it's for personal
    dangerous voltage points or short-out parts that          use only, recording copyrighted material is
    could result in a fire or electric shock.                 illegal without the permission of the copyright
    The apparatus shall not be exposed to dripping            holder.
    or splashing and no objects filled with liquids,     2.   AC Fuse--The AC fuse inside the unit is not
    such as vases shall be placed on the apparatus.           user-serviceable. If you cannot turn on the unit,
    Don't put candles or other burning objects on             contact your Onkyo dealer.
    top of this unit.                                    3.   Care--Occasionally you should dust the unit all
17. Batteries                                                 over with a soft cloth. For stubborn stains, use a
    Always consider the environmental issues and              soft cloth dampened with a weak solution of
    follow local regulations when disposing of                mild detergent and water. Dry the unit
    batteries.                                                immediately afterwards with a clean cloth. Don't
18. If you install the apparatus in a built-in                use abrasive cloths, thinners, alcohol, or other
    installation, such as a bookcase or rack, ensure          chemical solvents, because they may damage the
    that there is adequate ventilation.                       finish or remove the panel lettering.
    Leave 20 cm (8") of free space at the top and        4.   Power
    sides and 10 cm (4") at the rear. The rear edge of        WARNING
    the shelf or board above the apparatus shall be           BEFORE PLUGGING IN THE UNIT FOR
    set 10 cm (4") away from the rear panel or wall,          THE FIRST TIME, READ THE FOLLOWING
    creating a flue-like gap for warm air to escape.          SECTION CAREFULLY.
                                                              AC outlet voltages vary from country to country.
                                                              Make sure that the voltage in your area meets the
                                                              voltage requirements printed on the unit's rear
                                                              panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60
                                                              The power cord plug is used to disconnect this
                                                              unit from the AC power source. Make sure that
                                                              the plug is readily operable (easily accessible) at
                                                              all times.
                                                              For models with [POWER] button, or with both
                                                              [POWER] and [ON/STANDBY] buttons:
                                                              Pressing the [POWER] button to select OFF
                                                              mode does not fully disconnect from the mains.
                                                              If you do not intend to use the unit for an
                                                              extended period, remove the power cord from
                                                              the AC outlet.
                                                              For models with [ON/STANDBY] button only:
                                                              Pressing the [ON/STANDBY] button to select
                                                              Standby mode does not fully disconnect from
                                                              the mains. If you do not intend to use the unit for
                                                              an extended period, remove the power cord from
                                                              the AC outlet.
                                                         5.   Preventing Hearing Loss
                                                              Excessive sound pressure from earphones and
                                                              headphones can cause hearing loss.
                                                         6.   Batteries and Heat Exposure
                                                              Batteries (battery pack or batteries installed)
                                                              shall not be exposed to excessive heat as
                                                              sunshine, fire or the like.                           En
     7.   Never Touch this Unit with Wet Hands--                FCC Caution:
          Never handle this unit or its power cord while
          your hands are wet or damp. If water or any           FCC WARNING
          other liquid gets inside this unit, have it checked
                                                                Changes or modifications not expressly approved by
          by your Onkyo dealer.
                                                                the party responsible for compliance could void the
     8.   Handling Notes
                                                                user's authority to operate the equipment.
