Image preview - the first page of the document
Onkyo-SKW30 actsub

>> Download Onkyo-SKW30 actsub documenatation <<

Text preview - extract from the document

                                                                      Modified on 09/24/03

SKW-30 Subwoofer Parts List
EAMOSKW30P                        Pre-Amp with Harness. Order with,
1216SKW30                         Frequency Selector Knob
511SKW30                          Volume Knob

ELP2219                           +/_ Lead Set
EAMOSKW30                         Amplifier assembly
EWF61615P                         EWF61615P Woofer
EAC3M1C                           RCA Cable
12K / 3watt carbon                Resistor (obtain Locally)
EAMOSKW30-1                       Power Block Only. ( M3 ) Black Block in picture 3

1                            2                              3

Note: It is important to remove the knobs with care as not to damage front cabinet assembly.
When replacing any components on the pre-amplifier assembly it may be necessary to replace
the knobs that may be damaged as well.

1216SKW30                            Frequency Selector Knob
511SKW30                             Volume Knob
EAC3M1                               RCA cable
SKF110W                              Fuse AGC 2A 250V
SKW-30 Subwoofer Amplifier
