Image preview - the first page of the document

>> Download onkyo-tx-sr304e-users-manual-233490 documenatation <<

Text preview - extract from the document
                                                        Introduction ..................................... 2
AV Receiver

                                                        Connection .................................... 17

TX-SR304E                                               Turning On & First Time Setup..... 32

TX-SR8440                                               Basic Operation
                                                         Playing your AV components ....... 36
                                                         Using the Tuner............................ 38

Instruction Manual

                                                        Enjoying the Listening Modes ..... 45
Thank you for purchasing an Onkyo AV Receiver.
Please read this manual thoroughly before making
connections and plugging in the unit.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new AV Receiver.                    Advanced Operation ..................... 48
Please retain this manual for future reference.

                                                        Troubleshooting ............................ 55
                                                        Specifications................................ 58

     WARNING:                                                                WARNING                         AVIS
                                                                                  DO NOT OPEN              NE PAS OUVRIR
     TO RAIN OR MOISTURE.                                                 The lightning flash with arrowhead symbol, within an
                                                                          equilateral triangle, is intended to alert the user to the
     CAUTION:                                                             presence of uninsulated "dangerous voltage" within
     TO REDUCE THE RISK OF ELECTRIC SHOCK,                                the product's enclosure that may be of sufficient
                                                                          magnitude to constitute a risk of electric shock to
     DO NOT REMOVE COVER (OR BACK). NO                                    persons.
                                                                          The exclamation point within an equilateral triangle is
     SERVICING   TO   QUALIFIED   SERVICE                                 intended to alert the user to the presence of important
     PERSONNEL.                                                           operating and maintenance (servicing) instructions in
                                                                          the literature accompanying the appliance.

    Important Safety Instructions
     1.   Read these instructions.                               15. Damage Requiring Service
     2.   Keep these instructions.                                   Unplug the apparatus from the wall outlet and refer
     3.   Heed all warnings.                                         servicing to qualified service personnel under the
                                                                     following conditions:
     4.   Follow all instructions.                                   A. When the power-supply cord or plug is damaged,
     5.   Do not use this apparatus near water.                      B. If liquid has been spilled, or objects have fallen
     6.   Clean only with dry cloth.                                     into the apparatus,
     7.   Do not block any ventilation openings. Install in          C. If the apparatus has been exposed to rain or
          accordance with the manufacturer's instructions.               water,
     8.   Do not install near any heat sources such as radia-        D. If the apparatus does not operate normally by
          tors, heat registers, stoves, or other apparatus               following the operating instructions. Adjust only
          (including amplifiers) that produce heat.                      those controls that are covered by the operating
                                                                         instructions as an improper adjustment of other
     9.   Do not defeat the safety purpose of the polarized or           controls may result in damage and will often
          grounding-type plug. A polarized plug has two                  require extensive work by a qualified technician
          blades with one wider than the other. A grounding              to restore the apparatus to its normal operation,
          type plug has two blades and a third grounding             E. If the apparatus has been dropped or damaged in
          prong. The wide blade or the third prong are pro-              any way, and
          vided for your safety. If the provided plug does not       F. When the apparatus exhibits a distinct change in
          fit into your outlet, consult an electrician for               performance this indicates a need for service.
          replacement of the obsolete outlet.
                                                                 16. Object and Liquid Entry
    10.   Protect the power cord from being walked on or             Never push objects of any kind into the apparatus
          pinched particularly at plugs, convenience recepta-        through openings as they may touch dangerous volt-
          cles, and the point where they exit from the appara-       age points or short-out parts that could result in a
          tus.                                                       fire or electric shock.
    11.   Only use attachments/accessories specified by the          The apparatus shall not be exposed to dripping or
          manufacturer.                                              splashing and no objects filled with liquids, such as
    12.   Use only with the cart, stand, PORTABLE CART WARNING       vases shall be placed on the apparatus.
          tripod, bracket, or table spec-                            Don't put candles or other burning objects on top of
          ified by the manufacturer, or                              this unit.
          sold with the apparatus.                               17. Batteries
          When a cart is used, use cau-                              Always consider the environmental issues and fol-
          tion when moving the cart/                                 low local regulations when disposing of batteries.
          apparatus combination to                               18. If you install the apparatus in a built-in installation,
          avoid injury from tip-over.     S3125A
                                                                     such as a bookcase or rack, ensure that there is ade-
    13.   Unplug this apparatus during lightning storms or           quate ventilation.
          when unused for long periods of time.                      Leave 20 cm (8") of free space at the top and sides
    14.   Refer all servicing to qualified service personnel.        and 10 cm (4") at the rear. The rear edge of the shelf
          Servicing is required when the apparatus has been          or board above the apparatus shall be set 10 cm (4")
          damaged in any way, such as power-supply cord or           away from the rear panel or wall, creating a flue-like
          plug is damaged, liquid has been spilled or objects        gap for warm air to escape.
          have fallen into the apparatus, the apparatus has
          been exposed to rain or moisture, does not operate
          normally, or has been dropped.

1. Recording Copyright--Unless it's for personal use          For U.S. models
   only, recording copyrighted material is illegal with-
                                                              FCC Information for User
   out the permission of the copyright holder.
2. AC Fuse--The AC fuse inside the unit is not user-          CAUTION:
   serviceable. If you cannot turn on the unit, contact       The user changes or modifications not expressly
   your Onkyo dealer.                                         approved by the party responsible for compliance could
                                                              void the user's authority to operate the equipment.
3. Care--Occasionally you should dust the unit all
   over with a soft cloth. For stubborn stains, use a soft    NOTE:
   cloth dampened with a weak solution of mild deter-         This equipment has been tested and found to comply
   gent and water. Dry the unit immediately afterwards        with the limits for a Class B digital device, pursuant to
   with a clean cloth. Don't use abrasive cloths, thin-       Part 15 of the FCC Rules. These limits are designed to
   ners, alcohol, or other chemical solvents, because         provide reasonable protection against harmful interfer-
   they may damage the finish or remove the panel let-        ence in a residential installation.
   tering.                                                    This equipment generates, uses and can radiate radio
4. Power                                                      frequency energy and, if not installed and used in accor-
   WARNING                                                    dance with the instructions, may cause harmful interfer-
   BEFORE PLUGGING IN THE UNIT FOR THE                        ence to radio communications. However, there is no
   FIRST TIME, READ THE FOLLOWING SEC-                        guarantee that interference will not occur in a particular
   TION CAREFULLY.                                            installation. If this equipment does cause harmful inter-
   AC outlet voltages vary from country to country.           ference to radio or television reception, which can be
   Make sure that the voltage in your area meets the          determined by turning the equipment off and on, the
   voltage requirements printed on the unit's rear panel      user is encouraged to try to correct the interference by
   (e.g., AC 230
