Image preview - the first page of the document
>> Download XR-EM30(CX-LEM30EZ)_2 documenatation <<
Text preview - extract from the document
XR-EM30 HS(S),HR(S),
HT(S)
SERVICE MANUAL BASIC TAPE MECHANISM : CMAL5Z213B
CD STEREO SYSTEM
BASIC CD MECHANISM : KSM-213 RDM
REMOTE
SYSTEM CD CASSEIVER SPEAKER
CONTROLLER
XR-EM30 CX-SLEM30 SX-SLEM30 RC-CAS07
Replace this Service Manual with "Revision Publishing" when it is issued.
P LE
S IM
TA
DA
S/M Code No. 09-027-454-8T3
ELECTRICAL PARTS LIST -1/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
O A-P0002 S1-8A0-356-00N F-BCAD 035600 STYT Taping a b c
O C 0101 SC-E33-825-M10 CAP.E 3300UF25V M 85 IV a b c
X C 0102 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0102 SC-C22-250-0KA C-CAP, U 2200P-50V K X7R a b c
O C 0103 SC-E10-710-0MP Elect. Cap 100UF +/-20% 1 a b c
O C 0104 SC-E22-825-M30 CAP.E 2200UF 25V M 85 IV a b c
X C 0105 SC-C47-150-0JA C-CAP 470P 50V J C0G CER. a b c
O C 0106 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
O C 0106 SC-E10-710-0MP CAP.E,100-10 5L F=2.5mm a b c
O C 0107 SC-E47-550-0MP CAP,E 4.7-50M SSL F=5MM, a b c
O C 0108 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
O C 0109 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
O C 0110 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
O C 0111 SC-E10-750-0MP CAP,E 100-50 M SSL F=5MM, a b c
O C 0112 SC-E10-710-0MP Elect. Cap 100UF +/-20% 1 a b c
O C 0113 SC-E33-550-0MP CAP,E 3.3-50 M SSL F=5.5M a b c
O C 0114 SC-E47-610-0MP Cap. 47UF M Elec. 10V P=5 a b c
X C 0115 SC-M47-350-0JP Cap. 0.047uF J Poly F 50V a b c
X C 0116 SC-M47-350-0JP Cap. 0.047uF J Poly F 50V a b c
X C 0120 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0121 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0122 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
O C 0123 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
X C 0125 SC-M10-450-0JP Polyester Film Cap. 0.1uF a b c
X C 0126 SC-M10-450-0JP Polyester Film Cap. 0.1uF a b c
X C 0131 SC-C10-450-0ZA C-CAP.0.1UF-50V Z CER. a b c
X C 0132 SC-C10-450-0ZA C-CAP.0.1UF-50V Z CER. a b c
X C 0140 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0151 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X c 0203 SC-S22-225-0KP CAP, SC 2200P-25 K SR DD4 a b c
X c 0204 SC-S22-225-0KP CAP, SC 2200P-25 K SR DD4 a b c
X C 0205 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
X C 0206 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
O C 0207 SC-E10-550-0MP ELECT CAP 1UF +/-20% 50V a b c
O C 0208 SC-E10-550-0MP ELECT CAP 1UF +/-20% 50V a b c
O C 0209 SC-E10-550-0MP ELECT CAP 1UF +/-20% 50V a b c
O C 0210 SC-E10-550-0MP ELECT CAP 1UF +/-20% 50V a b c
X C 0211 SC-M68-350-0JP Cap.0.068 uF J POLY F 50V a b c
X C 0212 SC-M68-350-0JP Cap.0.068 uF J POLY F 50V a b c
O C 0213 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
O C 0214 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
X C 0215 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
X C 0216 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
X C 0217 SC-C56-316-0ZA C-CAP,U 0.056uF 16V Z F S a b c
X C 0218 SC-C56-316-0ZA C-CAP,U 0.056uF 16V Z F S a b c
X C 0219 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0220 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0221 SC-C15-350-0KA C-CAP 0.015u 25V K CER.EI a b c
X C 0222 SC-C15-350-0KA C-CAP 0.015u 25V K CER.EI a b c
X C 0223 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0224 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0225 SC-C10-110-1JA C-CAP,S 100P-100 J CH a b c
X C 0226 SC-C10-110-1JA C-CAP,S 100P-100 J CH a b c
X C 0227 SC-C47-250-0KA C-CAP, U 4700P-50V K X7R a b c
X C 0235 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0236 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0238 SC-C22-250-0KA C-CAP, U 2200P-50V K X7R a b c
O C 0268 SC-E47-616-0MP Cap. 47UF M Elec. 16V P=5 a b c
X C 0271 SC-M15-350-0JP Cap.0.015uF J Poly F 50V a b c
X C 0272 SC-M15-350-0JP Cap.0.015uF J Poly F 50V a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0274 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0275 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
O C 0283 SC-E10-710-0MP Elect. Cap 100UF +/-20% 1 a b c
O C 0284 SC-E10-710-0MP Elect. Cap 100UF +/-20% 1 a b c
X C 0301 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0302 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
O C 0304 SC-E10-650-0MP Elect.Cap 10uF M 50V Pitc a b c
O C 0307 SC-E47-550-0MP Cap.4.7uF M Elec. 50V P=2 a b c
O C 0308 SC-E47-550-0MP Cap.4.7uF M Elec. 50V P=2 a b c
X C 0309 SC-C22-325-0KA C-CAP, U 0.022UF-25V K X7 a b c
O C 0310 SC-E22-710-0MP Cap.220UF-10V M ELECT. Pi a b c
X C 0312 SC-H22-350-0KM Cap. 0.022uF K 50V B TYP a b c
O C 0314 SC-E33-706-3MP CAP E 330uF 6.3V M PITCH= a b c
X C 0315 SC-C22-416-0ZA C-CAP. U 0.22UF-16V Z Y5V a b c
X C 0329 SC-C22-325-0KA C-CAP, U 0.022UF-25V K X7 a b c
X C 0330 SC-C18-050-0JA C-CAP, U 18P-50V J C0G a b c
X C 0331 SC-C33-050-0JA C-CAP, U 33P-50V J C0G a b c
O C 0333 SC-E47-450-0MP E-Cap.0.47uF M Elec. 50V a b c
X C 0338 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0339 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
-3-
ELECTRICAL PARTS LIST -2/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0340 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0340 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
O C 0341 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
X C 0342 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0343 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0344 SC-C12-250-0KA C-CAP, U 1200P-50V K X7R a b c
O C 0348 SC-E22-710-0MP Cap. 220UF-10V M ELECT.P a b c
O C 0446 SC-E47-625-0MP Cap. 47UF M ELEC. 25V P=5 a b c
X C 0447 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0450 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0451 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0452 SC-E22-710-0MP Cap.220UF-10V M ELECT. Pi a b c
X C 0453 SC-C27-250-0KA C-CAP, U 2700P-50V K X7R a b c
X C 0454 SC-C27-250-0KA C-CAP, U 2700P-50V K X7R a b c
X C 0455 SC-C27-250-0KA C-CAP, U 2700P-50V K X7R a b c
X C 0456 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0457 SC-M56-210-1JP CAP.M.5600P-100 J CP a b c
X C 0458 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0459 SC-C56-150-0KA C-CAP, U 560P-50V K X7R a b c
X C 0461 SC-C39-150-0KA C-CAP, U 390P-50V K X7R a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0462 SC-C39-150-0KA C-CAP, U 390P-50V K X7R a b c
O C 0501 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
X C 0502 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0503 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
O C 0504 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
O C 0505 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
X C 0506 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0507 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0508 SC-C22-410-0KA C-CAP 0.22uF 10V K B SIZE a b c
X C 0509 SC-C33-316-0KA C-CAP, U 0.033UF-16V K X7 a b c
X C 0510 SC-C33-150-0JA C-CAP, U 330P-50V J C0G a b c
X c 0511 SC-C33-416-0KA C-CAP S. 0.33UF K Cer. a b c
X C 0512 SC-C15-325-0KA C-CAP, U 0.015UF-25V K X7 a b c
X C 0513 SC-C15-416-0KA C-CAP,S 0.15UF-16V K CER. a b c
X C 0514 SC-C22-250-0KA C-CAP, U 2200P-50V K X7R a b c
X C 0515 SC-C22-325-0KA C-CAP, U 0.022UF-25V K X7 a b c
X C 0516 SC-C47-316-0JA C-CAP,U 0.047uF 16V J B S a b c
X C 0517 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0518 SC-C15-150-0JA C-CAP, U 150P-50V J C0G a b c
X C 0519 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0520 SC-C47-250-0KA C-CAP, U 4700P-50V K X7R a b c
X C 0521 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
X C 0522 SC-C22-410-0KA C-CAP 0.22uF 10V K B SIZE a b c
X C 0523 SC-C33-250-0KA C-CAP, U 3300P-50V K X7R a b c
X C 0524 SC-C10-510-0KA C-CAP.S 1UR 10V K CER a b c
O C 0525 SC-E47-616-0MP E-CAP 47uF, +/-20% 16V a b c
X C 0527 SC-C08-050-0DA C-CPA, U 8 P-50V D C0G a b c
X C 0529 SC-C33-250-0KA C-CAP, U 3300P-50V K X7R a b c
X C 0530 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0531 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0532 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
O C 0533 SC-E47-550-0MP Cap.4.7UF M Elec.50V P=2. a b c
X C 0534 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0535 SC-E47-616-0MP E-CAP 47uF, +/-20% 16V a b c
X C 0536 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0537 SC-E10-650-0MP Elect. Cap. 10UF +/-20% 5 a b c
X C 0538 SC-C33-316-0KA C-CAP, U 0.033UF-16V K X7 a b c
X C 0539 SC-C10-510-0KA C-CAP.S 1UR 10V K CER a b c
X C 0540 SC-C15-416-0KA C-CAP,S 0.15UF-16V K CER. a b c
O C 0541 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0542 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0551 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0552 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0581 SC-E47-710-0MP CAP.E.470-10 M SMG a b c
X C 0582 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0583 SC-E47-616-0MP E-CAP 47uF, +/-20% 16V a b c
X C 0584 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0601 SC-C12-250-0KA C-CAP, U 1200P-50V K X7R a b c
X C 0602 SC-C12-250-0KA C-CAP, U 1200P-50V K X7R a b c
X C 0603 SC-C33-250-0KA C-CAP, U 3300P-50V K X7R a b c
X C 0604 SC-C33-250-0KA C-CAP, U 3300P-50V K X7R a b c
O C 0611 SC-E22-450-0MP CAP,E 0.22-50 M SSL F=5MM a b c
O C 0612 SC-E22-450-0MP CAP,E 0.22-50 M SSL F=5MM a b c
O C 0613 SC-E47-450-0MP ELECT CAP 0.47UF +/-20% 5 a b c
O C 0614 SC-E47-450-0MP ELECT CAP 0.47UF +/-20% 5 a b c
X C 0615 SC-C10-050-0DA C-CAP, U 10P-50V D C0G a b c
O C 0616 SC-E47-650-0MP CAP,E 47-50 M SSL F=5MM, a b c
O C 0617 SC-E47-650-0MP CAP,E 47-50 M SSL F=5MM, a b c
O C 0619 SC-E47-550-0MP CAP,E 4.7-50M SSL F=5MM, a b c
O C 0620 SC-E47-550-0MP CAP,E 4.7-50M SSL F=5MM, a b c
-4-
ELECTRICAL PARTS LIST -3/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0627 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0628 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0637 SC-C68-050-0JA C-CAP, U 68P-50V J C0G a b c
X C 0638 SC-C68-050-0JA C-CAP, U 68P-50V J C0G a b c
X C 0639 SC-C47-150-0JA C-CAP 470P 50V J C0G CER. a b c
X C 0640 SC-C47-150-0JA C-CAP 470P 50V J C0G CER. a b c
X C 0641 SC-C68-250-0KA C-CAP, U 6800P-50V X7R a b c
X C 0642 SC-C68-250-0KA C-CAP, U 6800P-50V X7R a b c
O C 0643 SC-E22-616-0MP Elect. Cap. 22UF +/-20% 1 a b c
O C 0644 SC-E22-616-0MP Elect. Cap. 22UF +/-20% 1 a b c
X C 0645 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0646 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0647 SC-C47-250-0KA C-CAP, U 4700P-50V K X7R a b c
X C 0648 SC-C47-250-0KA C-CAP, U 4700P-50V K X7R a b c
X C 0649 SC-C18-150-0JA C-CAP, U 180P-50V J C0G a b c
X C 0650 SC-C18-150-0JA C-CAP, U 180P-50V J C0G a b c
O C 0651 SC-E22-550-0MP CAP,E 2.2-50M SSL F=5MM, a b c
O C 0652 SC-E22-550-0MP CAP,E 2.2-50M SSL F=5MM, a b c
X C 0660 SC-C22-250-0KA C-CAP, U 2200P-50V K X7R a b c
X C 0661 SC-C22-250-0KA C-CAP, U 2200P-50V K X7R a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0663 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0670 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0703 SC-C12-250-0KA C-CAP, U 1200P-50V K X7R a b c
X C 0704 SC-C12-250-0KA C-CAP, U 1200P-50V K X7R a b c
X C 0725 SC-H10-350-0KN Axial Cer Cap. 0.01uF +/- a b c
X C 0729 SC-H10-350-0KN Axial Cer Cap. 0.01uF +/- a b c
X C 0772 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0779 SC-C12-325-0KA C-CAP, U 0.012UF-25V K X7 a b c
X C 0780 SC-C12-325-0KA C-CAP, U 0.012UF-25V K X7 a b c
X C 0783 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0784 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0785 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0786 SC-C22-325-0KA C-CAP. 0.022u 25V SIZE:16 a b c
X C 0788 SC-C05-050-0CA C-CAP 5.0P 50V SIZE:1608 a b c
X C 0789 SC-C22-325-0KA C-CAP. 0.022u 25V SIZE:16 a b c
X C 0790 SC-C22-325-0KA C-CAP. 0.022u 25V SIZE:16 a b c
X C 0792 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0793 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
X C 0794 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0795 SC-C10-325-0KA Multi-layer ceramic chip a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
O C 0799 SC-E33-625-0MP Elect CAP 33uF 25V M Pitc a b c
X C 0800 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0801 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
X C 0801 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0802 SC-C47-316-0ZA C-Cap U 0.047uF 16V Z Y5V a b c
X C 0802 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0803 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0804 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
O C 0804 SC-E10-710-0MP Elect. Cap. 100UF +/-20% a b c
X C 0805 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0806 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0807 SC-C47-410-0ZA C-CAP,U 0.47uF 10V Z Y5V a b c
X C 0808 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
X C 0809 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
X C 0810 SC-C10-416-0ZA C-CAP S 0.1uF 16V Z Y5V S a b c
X C 0811 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0814 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0814 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0815 SC-C47-410-0ZA C-CAP,U 0.47uF 10V Z Y5V a b c
X C 0816 SC-C47-410-0ZA C-CAP,U 0.47uF 10V Z Y5V a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0818 SC-M18-210-1JP Cap.0.0018UF J Mylar 100V a b c
X C 0819 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0821 SC-C47-510-0ZA C-CAP,S 4.7uF 10V Z Y5V s a b c
X C 0822 SC-C82-050-0JA C-CAP 82P 50V SIZE:1608 a b c
X C 0823 SC-H22-150-0JM CAP.220PF +/-5% 50V a b c
X C 0823 SC-C68-150-0KA C-CAP, U 680P 50V K CER X a b c
X C 0824 SC-C47-510-0ZA C-CAP,S 4.7uF 10V Z Y5V s a b c
X C 0825 SC-C68-316-0KA C-CAP 0.068U 16V SIZE:160 a b c
O C 0831 SC-E22-625-0MP Elect. Cap. 22 UF/25V M a b c
X C 0837 SC-C22-416-0ZA C-CAP 0.22U 16V SIZE:1608 a b c
X C 0841 SR-C00-001-65A C-JUMPER, JR 1/16W J a b c
X C 0842 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0845 SR-C00-001-65A C-JUMPER, JR 1/16W J a b c
X C 0849 SR-C00-001-65A C-JUMPER, JR 1/16W J a b c
X C 0850 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
O C 0851 SC-E22-710-0MP Cap. 220UF-10V M ELECT.P a b c
X C 0851 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0852 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0852 SC-C10-325-0KA Multi-layer ceramic chip a b c
O C 0853 SC-E47-710-0MP CAP.E.470-10 M SMG a b c
-5-
ELECTRICAL PARTS LIST -4/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0853 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0854 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
O C 0855 SC-E22-625-0MP Elect. Cap. 22 UF/25V M a b c
X C 0856 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0858 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0859 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0860 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0860 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0861 SC-C22-150-0JA C-CAP, U 220P-50V J C0G a b c
X C 0861 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0862 SC-C15-150-0JA C-CAP, U 150P-50V J C0G a b c
X C 0864 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0866 SC-C10-050-0DA C-CAP, U 10P-50V D C0G a b c
X C 0867 SC-C08-050-0DA C-CPA, U 8 P-50V D C0G a b c
O C 0868 SC-E47-550-0MP Cap.4.7UF M Elec.50V P=2. a b c
X C 0869 SC-C10-325-0KA C-CAP, U 0.01UF-25V K X7R a b c
X C 0871 SC-C10-150-0JA C-CAP, U 100P-50V J C0G a b c
X C 0872 SC-C10-425-0ZA C-CAP, U 0.1UF-25V Z Y5V a b c
X C 0873 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0881 SC-C47-150-0JA C-CAP 470P 50V J C0G CER. a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0882 SC-C47-150-0JA C-CAP 470P 50V J C0G CER. a b c
O C 0883 SC-E47-450-0MP Cap.0.47UF M Elec. 50V a b c
O C 0884 SC-E47-450-0MP Cap.0.47UF M Elec. 50V a b c
X C 0885 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0886 SC-C10-250-0KA C-CAP, U 1000P-50V K X7R a b c
X C 0901 SC-C07-050-0DA Multi-layer ceramic chip a b c
X C 0906 SR-C00-001-65A C-JUMPER, JR 1/16W J a b c
X C 0909 SC-C10-250-0KA C-CAP 1000P 50V SIZE:1608 a b c
X C 0911 SC-C08-050-0DA C-CAP 8.0P 50V SIZE:1608 a b c
X C 0912 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0914 SC-C10-350-0KA Ceramic Capacitor U 0.01U a b c
X C 0915 SC-C10-350-0KA Ceramic Capacitor U 0.01U a b c
X C 0917 SC-C02-050-0CA C-CAP 2.0P 50V SIZE:1608 a b c
X C 0920 SC-C22-050-0JA C-CAP, 22P 50V SIZE:1608 a b c
X C 0921 SC-C39-050-0JA C-CAP 39P 50V SIZE:1608 a b c
X C 0922 SC-C12-050-0JA Multi-layer ceramic chip a b c
X C 0923 SC-C47-150-0KA C-CAP 470P 50V SIZE:1608 a b c
X C 0924 SC-C01-050-0CA Multi-layer ceramic chip a b c
X C 0926 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0927 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0931 SC-C10-425-0KA C-CAP,U 0.1uF K 25V B SIZ a b c
X C 0932 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0933 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0934 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0935 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0936 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0937 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0938 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0939 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0961 SC-C10-050-0DA C-CAP 10P 50V SIZE:1608 a b c
X C 0962 SC-C10-510-0ZA C-CAP U 1uF 10V Z Y5V SIZ a b c
X C 0963 SC-C10-416-0ZA C-CAP,U 0.1uF 16V Z Y5V S a b c
O C 0971 SC-E33-716-0MP Cap.330uF-16V M ELECT.PIT a b c
X C 0972 SC-C47-510-0ZA C-CAP,S 4.7uF 10V Z Y5V s a b c
X C 0973 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0974 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0976 SC-C10-416-0ZA C-CAP,U 0.1uF 16V Z Y5V S a b c
X C 0979 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
O C 0981 SC-E47-616-0MP E-CAP 47uF, +/-20% 16V a b c
X C 0982 SC-C10-416-0ZA C-CAP,U 0.1uF 16V Z Y5V S a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
X C 0983 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0984 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0985 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0987 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0988 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0989 SC-C10-325-0KA Multi-layer ceramic chip a b c
X C 0990 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0991 SC-C15-050-0JA C-CAP 15P 50V SIZE:1608 a b c
X C 0992 SC-C15-050-0JA C-CAP 15P 50V SIZE:1608 a b c
X C 0993 SC-C10-250-0KA C-CAP 1000P 50V SIZE:1608 a b c
X C 0994 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0995 SC-C10-250-0KA C-CAP 1000P 50V SIZE:1608 a b c
X C 0996 SC-C10-150-0JA C-CAP 100P 50V SIZE:1608 a b c
X C 0997 SC-C10-416-0ZA C-CAP,U 0.1uF 16V Z Y5V S a b c
O C 0998 SC-E47-616-0MP E-CAP 47uF, +/-20% 16V a b c
X C 0999 SC-C10-325-0KA Multi-layer ceramic chip a b c
O C-B0000 S1-8A0-356-00N F-BCAD 035600 STYT Taping a b c
O CF 0831 S2-900-081-000 FM Ceramic Filter 10.7 MH a b c
O CF 0832 S2-900-081-000 FM Ceramic Filter 10.7 MH a b c
O CN 0101 S1-2S5-012-900 Socket,CONN 5PIN V WHI EH a b c
-6-
ELECTRICAL PARTS LIST -5/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
O CN 0301 S1-2S3-000-020 Connector 30P (DC:125V/0, a b c
O CN 0302 S1-2S7-001-520 7PINS FFC SOCKET ANGLE TY a b c
O CN 0351 S1-2S7-002-200 CONN 7P V H TYPE 2MM JMT a b c
O CN 0501 S1-2S1-600-080 CONN, 16P V TOC-B a b c
O cn 0502 S1-2P6-010-300 6P Conn.Assy PITCH=2.0mm a b c
O CN 0601 S1-2S3-000-010 Connector 30P H (DC:125V/ a b c
O CN 0702 S1-2S1-300-200 BOARD TO BOARD CONN. SOC a b c
O CN 0802 S1-2S2-001-620 2Pins Socket (150V) (DC:5 a b c
O CN 0803 S1-2S2-001-620 2Pins Socket (150V) (DC:5 a b c
O CN 0991 S1-2S1-300-260 TUC-P connector 13Pin TUC a b c
O CNA0001 S1-2P2-018-900 2PINS CONNECTOR ASSY L=26 a b c
S D 0100 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0101 S3-1N4-148-M00 Diode IN-4148,26mm TAPE a b c
S D 0101 S3-1N5-393-GWN DIODE, 1N5393 GW 52mm Tap a b c
S D 0102 S3-1N5-393-GWN DIODE, 1N5393 GW 52mm Tap a b c
S D 0103 S3-1N5-393-GWN DIODE, 1N5393 GW 52mm Tap a b c
S D 0104 S3-1N5-393-GWN DIODE, 1N5393 GW 52mm Tap a b c
S D 0104 S3-UZ5-6BS-AM0 ZENER UZ5.6BSA 26mm TAPE a b c
S D 0105 S3-1N4-148-M00 Diode IN-4148,26mm TAPE a b c
S D 0105 S3-1N4-003-LEM DIODE,1N4003 LES a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
S D 0106 S3-1N4-003-LEM DIODE,1N4003 LES a b c
S D 0107 S3-UZ2-7BS-DM0 ZENER,UZ27BSD 26mm TAPE a b c
X D 0108 SR-C12-300-85M RES 12 K 1/8W J 26mm TAPE a b c
S D 0109 S3-MC2-836-A00 C-DIODE MC2836 a b c
S D 0110 S3-UZ1-0BS-CM0 ZENER,UZ10BSC 26mm TAPE a b c
S D 0112 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0116 S3-1N4-003-LEM DIODE,1N4003 LES a b c
S D 0117 S3-1N4-003-LEM DIODE,1N4003 LES a b c
S D 0171 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0201 S3-MC2-836-A00 C-DIODE MC2836 a b c
S D 0202 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0203 S3-MC2-836-A00 C-DIODE MC2836 a b c
S D 0204 S3-MC2-836-A00 C-DIODE MC2836 a b c
S D 0205 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0206 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0207 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0208 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0209 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0301 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0301 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
S D 0302 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0318 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0581 S3-1N4-003-LEM DIODE,1N4003 LES a b c
S D 0601 S3-UZ4-7BS-AM0 ZENER UZ4.7BSA 26mm a b c
S D 0602 S3-UZ4-7BS-AM0 ZENER UZ4.7BSA 26mm a b c
X D 0603 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
S D 0604 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
X D 0801 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
S D 0803 S3-1SS-133-M00 Diode 1SS133 26mm TAPE a b c
S D 0851 S3-MC2-838-A00 C-DIODE MC2838 a b c
S D 0852 S3-MC2-838-A00 C-DIODE MC2838 a b c
X D 0896 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
O D 0902 S3-HVC-202-A00 C-DIODE VARI-CAP, HVC 202 a b c
O D 0903 S3-HVC-202-A00 C-DIODE VARI-CAP, HVC 202 a b c
O D 0951 S3-KV1-610-SA0 C-VARI,CAP KV1610S SOT23- a b c
S D 0991 S3-HZS-6A2-LM0 ZENER, HZS6A2L a b c
X F 0101 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
O F 0102 S4-001-610-000 T3.15AL AC:250V (5x20)mm a b c
O F 0103 S4-001-610-000 T3.15AL AC:250V (5x20)mm a b c
O FB 0110 S2-6BK-212-5HA C-COIL BK2125HM601 a b c
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
O FB 0111 S2-6BK-212-5HA C-COIL BK2125HM601 a b c
X FB 0201 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
O FB 0602 S2-6BK-212-5HA C-COIL BK2125HM601 a b c
O FB 0618 S1-8A0-356-00N F-BCAD 035600 STYT Taping a b c
X FB 3 HT S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
O FC 0103 S2-011-960-101 Fuse Holder (87-A90-160-0 a b c
O FC 0104 S2-011-960-101 Fuse Holder (87-A90-160-0 a b c
O FC 0105 S2-011-960-101 Fuse Holder (87-A90-160-0 a b c
O FC 0106 S2-011-960-101 Fuse Holder (87-A90-160-0 a b c
O FL 0301 S2-701-681-000 VACUUM FLUORESCENT DISPLA a b c
O FOR0000 S1-2P7-005-620 CONN ASSY 7Pins RPEH, P=2 a b c
O FOR0000 S1-2P2-018-700 CONN ASSY, 2P CD DOOR P=2 a b c
O FOR0000 S1-204-182-000 FF-CABLE PITCH=1.25mm L=9 a b c
O FOR0000 S1-203-761-000 FF-CABLE,16P 1.0 CD L=(4+ a b c
X HRJ0000 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
X HS 0000 S5-283-A00-000 "R-3" (Kin Fung) Tin Coa a b c
S IC 0102 S1-100-710-000 IC , NJM7806FA 6V REGULAT a b c
S IC 0301 S1-133-410-000 C-IC,LC876748A-5Z32 a b c
S IC 0303 S1-052-310-000 IC RPM6938-V4 REMOTE CONT a b c
S IC 0501 S1-037-610-000 C-IC LA9241ML a b c
-7-
ELECTRICAL PARTS LIST -6/17
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.
UNIT-NAME ! C REF-NO PARTS-NO PARTS-NAME SUFFIX&MODEL
XR-EM30 XR-EM30 XR-EM30
HSSC HRJSC HTSC
S IC 0551 S1-120-610-000 C-IC,BU4066BCF(SOP14) a b c
S IC 0581 S1-133-010-000 C-IC CD-DRIVER BA5949FP a b c
S IC 0601 S1-127-210-000 C-IC,BD3881FV a b c
S IC 0801 S1-133-310-000 IC,LA1845N-A DIP-24 a b c
S IC 0851 S1-027-130-000 C-IC LC78622NE DSP a b ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
