Image preview - the first page of the document



>> Download CX-JT8 documenatation <<

Text preview - extract from the document

                                                                                                                             CX-JT8
SERVICE MANUAL                                                                                                                               AEP Model
                                                                                                                                               UK Model
Ver 1.0 2003.04
                                                                                                                                                 E Model
                                                                                                                                        Australian Model




CX-JT8 is the tumer, amplifier, casette deck and
CD player section in JAX-T8 and JAX-PK8.



                                                                            Model Name Using Similar Mechanism                 NEW
                                                                            CD Mechanism Type                                  CDM74F-K6BD71A
                                                         CD
                                                                            Base Unit Name                                     BU-K6BD71A
                                                         Section
                                                                            Optical Block Name                                 KSM-213DCP
                                                                            Optical Pick-up Name                               KSS-213D

                                                         Tape deck          Model Name Using Similar Mechanism                 NEW
                                                         Section            Tape Transport Mechanism Type                      CWM43RR23


                                                                                 SPECIFICATIONS
TUNER                                                             CASSETTE DECK                                             GENERAL
FM tuning range               87.5 MHz to 108 MHz                 Track format            4 tracks, 2 channels stereo       Power requirements         230 V AC, 50/60 Hz
FM usable sensitivity (IHF)   16.8 dBf                            Frequency response      50 Hz
