Image preview - the first page of the document



>> Download hfe_aiwa_csd-xm77_service_en documenatation <<

Text preview - extract from the document

                                                                      CSD-XM77
SERVICE MANUAL                                                                                      Canadian Model
                                                                                                         AEP Model
Ver 1.0 2004. 06
                                                                                                           UK Model
                                                                                                             E Model
                                                                                                    Australian Model




                                                                              Model Name Using Similar Mechanisma       CSD-XD55
                                                                        CD
                                                                              CD Mechanism Type                         KSM-213RDP
                                                                      Section
                                                                              Optical Pick-up Name                      KSS-213R

                                                                        TC    Model Name Using Similar Mechanism        CSD-XD55
                                                                      Section Tape Transport Mechanism Type             MF-XD55


                                                          SPECIFICATIONS
CD player section                                                     Radio section
System Compact disc digital audio system                              Frequency range
Laser diode properties                                                         European model
          Material: GaAlAs
                                                                               FM     87.5 - 108 MHz
          Wave length: 780 nm
          Emission duration: Continuous                                        MW     531 - 1,611 kHz (9 kHz step)
          Laser output: Less than 44.6
