Image preview - the first page of the document



>> Download hfe_aiwa_cx-lfa880_service_en documenatation <<

Text preview - extract from the document

                                                                             CX-LFA880
SERVICE MANUAL                                                                                                           AEP Model
                                                                                                                             E Model
Ver. 1.2 2005.02
                                                                                                                    Australian Model




CX-LFA880 is the Amplifier , DVD player, Tape
Deck and Tuner section in XR-FA880DVD.



This system incor porates Dolby1) Digital and DTS 2) Digital                 DVD        Model Name Using Similar Mechanism                NEW
Surround System.
1) Manufactured under license from Dolby Laboratories.                       Section    DVD Mechanism Type                                KDA898ST
   "Dolby", "Pro Logic", and the double-D symbol are trademarks              TAPE       Model Name Using Similar Mechanism                CX-LFA660
    of Dolby Laboratories.
2) Manufactured under license from Digital Theater Systems,                  Section    Tape Transport Mechanism Type                     CMAL1Z240A
    Inc. "DTS" and "DTS 2.0 + Digital Out" are trademarks of
    Digital Theater Systems, Inc.


                                                                  SPECIFICATIONS

Amplifier section                                    S VIDEO OUT (4-pin/mini-DIN jack):                  Disc player section
European model                                                               Y: 1 Vp-p, unbalanced,      System                      Compact disc and digital
The following measured at AC 230 V, 50/60 Hz                                 Sync negative,                                          audio and video system
DIN power output (rated) 25 + 25 watts                                       C: 0.286 Vp-p for NTSC,     Laser                       Semiconductor laser
                          (6 ohms at 1 kHz, DIN)                             load impedance 75 ohms                                  (DVD: =650 nm,
Continuous RMS power output (reference)                                      C: 0.3 Vp-p for PAL,                                    CD: =780 nm)
                          30 + 30 watts                                      load impedance 75 ohms                                  Emission duration:
                          (6 ohms at 1 kHz, 10%      LINE-TV (for European model):                                                   continuous
                          THD)                                               max. output level 1 Vp-p,   Frequency response          DVD (PCM 48 kHz):
Music power output (reference)                                               unbalanced, Sync                                        2 Hz
