Image preview - the first page of the document
>> Download Aiwa-HV-FX5100-Service-Manual documenatation <<
Text preview - extract from the document
HV-FX5100 K
SERVICE MANUAL
VIDEO CASSETTE RECORDER BASIC TAPE MECHANISM : OVD-6
SPECIFICATIONS
POWER REQUIREMENTS ................. 230 V AC, 50 Hz HI-FI WOW AND FLUTTER ............. Less than 0.01% (nominal)
POWER CONSUMPTION ................... 17W TAPE SPEED ................................... PAL SP: 23.39 mm/sec
WEIGHT .............................................. 3.5 kg (7.7 lbs.) LP: 11.69 mm/sec
DIMENSIONS ...................................... 380 mm (W) x 267 mm (D) x NTSC (playback only)
95 mm (H) SP: 33.35 mm/sec
(15 x 10 5/8 x 3 3/4 in.) RECORDING/PLAYBACK TIME ..... PAL SP: 5 hours with E-300 tape
