                             Service Technical Information
  MODEL NO.
                 NSX -SZ50 / SZ52 / BL54 / BL56


  SUBJECT
                 Poping sound from the speaker during POWER ON             REF.No. :G - A0 - 007 - E0

                                                                           DATE      :08. MAY. 2000


   It is reported that when power is turned on with ECO on, a momentary poping sound may
   comes out from the speakers.
   Take the following actions against the above problem.



   1) Attach CUSH -S, PWB.
   2) Connect the anode of the DIODE, 1SS133 to RES, 10 -1/8W by soldering.
   3) Connect the cathode of the DIODE, 1SS133 to the Q008 connector by soldering.
   4) Connect RES, 10 -1/8W to the plus side of C035 by soldering.
   5) Apply glue to the cathode of diode.
   6) Apply glue to the terminal of resistance.


    5) Apply glue to the cathode                                     3) Connect the cathode of the
       of diode.                                                       DIODE, 1SS133 to the Q008
                                                                        connector by soldering.
    1) Attach CUSH-S, PWB.

       2) Connect the anode of the
          DIODE, 1SS133 to RES,
          10-1/8W by soldering.


       6) Apply glue to the terminal
          of resistance.

       4) Connect RES, 10-1/8W
                                                                          MAIN C.B.
          to the plus side of C035
          by soldering.




       Ref.            Parts Code                 Description                       Remarks
         -          87-020-465- 080          DIODE, 1SS133                             -
         -          88-121-100- 070          RES, 10 -1/8W                             -
         -          80-XV1- 218 - 010        CUSH- S, PWB                              -


  G          R      Code No.            Access Code             Modified Ser. No.       Parts Schedule
   -         -          -                    -                   S  03 ~                       -
