Image preview - the first page of the document
>> Download AIWA.TSW 37 documenatation <<
Text preview - extract from the document
TS-W37 U EZ HR
SERVICE MANUAL
POWERD SUBWOOFER
TA
DA
S/M Code No. 09-003-342-3N1
SPECIFICATIONS
Input terminals INPUT 1 jack
INPUT 2 terminals
Input sensitivity/Impedance INPUT 1: 0.2 V/50 kiro ohms (at 60 Hz)
INPUT 2: 2 V/4.4 kiro ohms (L and R) (at 60 Hz)
Output terminals SPEAKERS OUT terminals
Power output
32 W (50 Hz to 120 Hz, T.H.D. less than 1%, 8 ohms)
40 W (8 ohms, T.H.D. 10% at 60 Hz)
32 W (8 ohms, T.H.D. 1% at 60 Hz)
40 W (8 ohms, T.H.D. 10% at 60 Hz)
Frequency response 45 Hz - 200 Hz
Speaker type Bass reflex type
Speaker unit 13 cm (51/8 in.) (Magnetically shielded type)
Power requirement
AC 120 V, 60 Hz
AC 230 V, 50 Hz
AC 120 V/220 V - 240 V switchable, 50/60 Hz
Power consumption 30 W
48 W
Dimensions 160 x 233 x 376 mm (W x H x D)
(63/8 x 91/8 x 147/8 in.)
Weight 5.8 kg (12 lbs 13 oz.)
