Image preview - the first page of the document
aiwa__azg_1_205


>> Download aiwa__azg_1_205 documenatation <<

Text preview - extract from the document
                        AZG-1                English




SERVICE MANUAL              BASIC CD MECHANISM:3ZG-2 E3
 CD MECHANISM                                  3ZG-2 YE3




                TYPE    BASIC CD MECHANISM
               SB3RMD       3ZG-2 YE3
              SB3RNMD
              SB3RMDM
            SB3RNMDM         3ZG-2 E3
             YSB3RMDM
            YSB3RNMDM
                                                         TA
                                                       DA




           S/M Code No. 09-001-335-3NE
PROTECTION OF EYES FROM LASER BEAM DURING SERVICING
This set employs laser. Therefore, be sure to follow carefully the        CAUTION
instructions below when servicing.                                        Use of controls or adjustments or performance of procedures
                                                                          other than those specified herein may result in hazardous
WARNING!                                                                  radiation exposure.
WHEN SERVICING, DO NOT APPROACH THE LASER EXIT
WITH THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO                      ATTENTION
CONFIRM LASER BEAM EMISSION. BE SURE TO OBSERVE                           L'utilisation de commandes, r
