Image preview - the first page of the document
>> Download vx-g142kpdf_454 documenatation <<Text preview - extract from the document VX-G142 K
SERVICE MANUAL
INTEGRATED COLOR TV/VIDEO
BASIC TAPE MECHANISM : OVD-5
CASSETTE RECORDER
SPECIFICATIONS
GENERAL
POWER REQUIREMENTS ................. 230V AC, 50Hz VIDEO HEAD ................................... Azimuth 2 head
POWER CONSUMPTION ................... 79W USABLE CASSETTES ..................... VHS video cassette
WEIGHT .............................................. 12.5 kg (27.5 lbs.) TAPE SPEED ................................... PAL
DIMENSIONS ...................................... 365(W) x 372(D) x 382(H) mm SP: 23.39mm/sec
(14 3/8 x 14 3/4 x 15 1/8 in.) LP: 11.69mm/sec
TV SECTION NTSC (Playback SP only)
PICTURE TUBE DEFLECTION .......... 14 in. (34cm "V"), 90 degree 33.35mm/sec
TUNER SYSTEM ................................ Voltage synthesized tuner RECORDING TIME .......................... PAL
CHANNEL COVERAGE ...................... UHF: 21 to 69 SP: 4 hours 20 minutes with
TV SYSTEM ........................................ I E-260 tape
HORIZONTAL RESOLUTION ............ 240 lines LP: 8 hours 40 minutes with
E-260 tape
VCR SECTION NTSC (Playback SP only)
OPERATING TEMPERATURE ........... 5
