Image preview - the first page of the document
>> Download vx-t147k_164 documenatation <<
Text preview - extract from the document
VX-T147 K
SERVICE MANUAL
INTEGRATED COLOR TV/VIDEO
BASIC TAPE MECHANISM : OVD-5
CASSETTE RECORDER
SPECIFICATIONS
GENERAL
POWER REQUIREMENTS ................. 230V AC, 50Hz VIDEO SIGNAL SYSTEM ................ PAL colour system, 625 lines,
POWER CONSUMPTION ................... 57W 50 fields
WEIGHT .............................................. 13.5 kg (29.7 lbs.) AUDIO TRACK ................................. 1 track (Mono)
DIMENSIONS ...................................... 435 mm (W) x 365 mm (D) x USABLE CASSETTES ..................... VHS video cassette
384.5 mm (H) TAPE SPEED ................................... PAL SP: 23.39 mm/sec
(17 1/8 x 14 3/8 x 15 1/4 in.) LP: 11.69 mm/sec
NTSC (Playback SP only)
TV SECTION 33.35 mm/sec
PICTURE TUBE .................................. 14" (34 cm "V"), 90 degree RECORDING TIME .......................... PAL SP: 4 hours 20 minutes
deflection with E-260 tape
TUNER SYSTEM ................................ Voltage synthesized tuner LP: 8 hours 40 minutes
CHANNEL COVERAGE ...................... UHF: 21 to 69 with E-260 tape
TV SYSTEM ........................................ I NTSC (Playback SP only)
HORIZONTAL RESOLUTION ............ 240 lines 3 hours with T-180 tape
VIDEO INPUT ................................... 1.0Vp-p, 75 ohm, unbalanced
VCR SECTION VIDEO OUTPUT .............................. 1.0Vp-p, 75 ohm, unbalanced
