>> Download mod.albrecht 5180 documenatation <<Text preview - extract from the documentAE 5180
Kanalerweiterung
D1 D2 D3
x x x 40FM/12AM
x x o 40FM/40AM
x o x 120FM/120AM (B - D)
x o o 40FM
o x x 80FM/80AM
o x o 80FM
o o x 80FM/12AM
o o o 200FM/200AM (A - E)
o = offen
x = Diode (1N4148)
