Image preview - the first page of the document

>> Download alpine_mrx-m100_sm documenatation <<

Text preview - extract from the document

 The following cautions will prevent accidents in the workplace and will ensure safe products.
*The symbols indicate caution is needed to prevent injuries and damage to property.
 The symbols and their meanings follow.

                         If you ignore this symbol and handle the product incorrectly or unsafely,
         Warning         serious injury or death may result.

                         If you ignore this symbol and handle the product incorrectly or unsafely,
         Caution         injury or only material damage may result.

*The following symbols indicate two levels of cautions.

         When you see this symbol, you have to be very careful.

         When you see this symbol, you have to follow the instructions there.

         Do not look squarely into the laser light                            Fuse Caution
         coming from the pickup.                                              Always use a designated fuse.
         You may loose you sight.                                             Use of an incorrect fuse may result in a fire.

         Do not allow wiring to be caught in the                              Battery Caution
         screw/chassis.                                                       Use the designated battery.
         If wiring is caught in the screw/chassis, it may                     Confirm the correct polarity and seat of the
         cause a short circuit, resulting in a fire.                          battery.
                                                                              An incorrect battery or an improperly connected
                                                                              or seated battery may result in a fire.

         High Temperature Caution                                             Designated Parts Caution
         Touching the heat sink may cause severe burns.                       Look up the part list and ensure that only
                                                                              designated parts are used to prevent problems or

         Reverse Power Supply Connections or                                  Wiring Caution
         Misconnections Caution                                               Ensure that the wiring is correct when rewiring to
         Reverse power supply connections or                                  prevent problems with ignition/breakdown.
         misconnections may cause ignition problems and
         smoke may result.

         Soldering Caution                                                    Wear Gloves
         Hot solder from solder splash may cause severe                       Wear gloves to prevent electrical shocks or injury
         burns.                                                               from the end face of the metal.
      201 101
                               4X 801
                4X 701
                Packing Method View
     101   68-13530Z78   MANUAL,OWNER'S
$1   102   68-13530Z79   MANUAL,OWNER'S(I,G,S)
     103   01E42129S01   CONN,ASSY 8P
     104   15E42152S01   COVER,TERMINAL-L
     105   15E42153S01   COVER,TERMINAL-R
     106   03E36690S01   WRENCH,2.5X2.9
     107   03E40419S01   SCR,M4X20(BLK)
     108   03E39167S01   SCR,M3X12(P)(BLK)
Mark Model Code
#1    MRX-M100(North American) Only,
$1    MRX-M100(European) Only,
%1 MRX-M100(General Foreign) Only,
NOTE:The part that has not PART NUMBER will not be supplied.

  Power Output                                 (1) 20Hz, 4ohm, 1.0% T.H.D. (14.4V)                      600W
                                                   100Hz, 4ohm, 1.0% T.H.D. (14.4V)                     600W
                                               (2) 20Hz, 2ohm, 1.0% T.H.D. (14.4V)                      1000W
                                                   100Hz, 2ohm, 1.0% T.H.D. (14.4V)                     1000W
                                               (3) 20Hz, 1ohm, 1.0% T.H.D. (14.4V)                      500W
                                                   100Hz, 1ohm, 1.0% T.H.D. (14.4V)                     500W

  T.H.D.                                       (1) 10W/4ohm at 20Hz / 100Hz (14.4V)                     0.04%
                                                   600W/4ohm at 20Hz / 100Hz (14.4V)                    0.50%
                                               (2) 10W/2ohm at 20Hz / 100Hz (14.4V)                     0.08%
                                                   1000W/2ohm at 20Hz / 100Hz (14.4V)                   1.00%

  Residual Noise (Input Short)                 (1) NON-FILTER + AUX-0025                                4mV

                                               (2) 22KHz LPF + IHF-A                                    Vol max : 600uV
                                                                                                        Vol cent : 250uV
                                                                                                        Vol min : 200uV

  S/N Ratio (Input Short)                      (1) Ref.Output 1W/4ohm, CEA-2006-A                       80dB
                                               (2) Ref.Output 600W/4ohm                                 107dB

  Frequency Response (Ref.Output 1W/4ohm, 100Hz)                                                        10Hz : -1.0
