Image preview - the first page of the document



>> Download LM730 documenatation <<

Text preview - extract from the document

SERVICE MANUAL

    17" LCD Monitor
             LM730




               P/N : 41A50-171
THESE DOCUMENTS ARE FOR REPAIR SERVICE INFORMATION ONLY. EVERY
REASONABLE EFFORT HAS BEEN MADE TO ENSURE THE ACCURACY OF THIS
MANUAL; WE CANNOT GUARANTEE THE ACCURACY OF THIS INFORMATION AFTER
THE DATE OF PUBLICATION AND DISCLAIMS RE LIABILITY FOR CHANGES, ERRORS
OR OMISSIONS,

MANUFACTURE DATA : Sep-29-2002
REVISE:            Sep-29-2002




                                  1
                                                  TABLE OF CONTENTS
PAGE
  1. SPECIFICATIONS ....................................................................................................            3
     1-1  GENERAL SPECIFICATIONS ....................................................................                               3
     1-2 LCD MONITOR DESCRIPTION ..................................................................                                 3
     1-3  INTERFACE CONNECTOR ........................................................................                              3

   2.    PRECAUTION AND NOTICES ................................................................................                    5
         2-1 ASSEMBLY PRECAUTION .........................................................................                          5
         2-2 OPERATIONG PRECAUTION .....................................................................                            5
         2-3 STORAGE PRECAUTION ...........................................................................                         5
         2-4 HIGH VOLTAGE WARNING .......................................................................                           5

   3.    OPERATING INSTRUCTIONS ................................................................................                    6

   4.    ADJUSTMENT ..........................................................................................................       7
         4-1 ADJUSTMENT CONDITIONS AND PRECAUTIONS ...............................                                                   7
         4-2 ADJUSTMENTS METHOD .& DESCRIPTION......................................                                               7-8
         4-3 FRONT PANEL CONTROL KNOBS ............................................................                                  9

   5.    CIRCUIT & SOFTWARE DESCRIPTION .............,.....................................                                         10
         5-1 SPECIAL FUNCTION WITH PRESS KEY .....................................                                                  10
         5-2  CIRCUIT FUNCTION DESCRIPTION..........................................                                             10-11
         5-3  SOFTWARE FLOW CHART......................................................                                             12

   6. A).         INTERFACE-BOARD TROUBLE-SHOOTING CHART ........................                                                14-21
      B).         INVERTER
