Image preview - the first page of the document



>> Download 5989-7277EN English _ 2014-07-31 _ PDF 638 KB c20140829 [33] documenatation <<

Text preview - extract from the document

Keysight Technologies
11713B/C Attenuator/Switch Drivers


Coniguration Guide
This configuration guide will assist you through the process of configuring a switching system using the Keysight
Technologies, Inc. 11713B/C attenuator/switch drivers.



Key Features
The 11713B attenuator/switch driver is a GPIB compatible instrument that concurrently drives up to two four-section
programmable step attenuators and two microwave coaxial switches, or up to 10 SPDT switches2. The 11713B is fully
backward compatible with the 11713A in terms of functionality and fit. Connectivity using USB and LAN are optional.

The 11713C attenuator/switch driver is a GPIB/USB/LAN compatible instrument that concurrently drives up to four
programmable step attenuators and four microwave coaxial switches, or up to 20 SPDT switches2. The 11713C comes
with tri-voltage selection of 5 V, 15 V and 24 V and also permits user-defined voltage supply capability.
