Image preview - the first page of the document
![5989-7321EN 81600B Tunable Laser Source Family - Data Sheet c20140926 [14]](/pics/5c2173fa69274.gif)
>> Download 5989-7321EN 81600B Tunable Laser Source Family - Data Sheet c20140926 [14] documenatation <<
Text preview - extract from the document
Keysight Technologies
81600B Tunable Laser Source Family
Data Sheet
Introduction
The Keysight Technologies, Inc. 81600B Tunable Laser Source Family offers the
full wavelength range from 1260 nm to 1640 nm with no wavelength gaps. This
provides test instrumentation with maximum flexibility.
Investing in the Keysight 81600B Tunable Laser Source Family can realize the
cost efficiency and performance required to test components for coarse and
dense wavelength division multiplexing (CWDM, DWDM) and passive optical
networks (PON).
Keysight 81600B Tunable Integrated solutions for Specified performance in the
Laser Source Family swept-wavelength spectral continuous sweep mode
The Keysight 81600B Tunable Laser measurements As manufacturing yield expectations
Source Family consists of seven The 81600B is supported with the becomes more and more stringent,
modules that fit into the bottom slot N7700A software suite for spectral it is important that all instruments
of the Keysight 8164B Lightwave measurements of insertion loss, deliver optimum performance under
Solution Mainframe. polarization dependent loss and all measurement conditions.
The 81600B Option 200 and 201 All- dispersion in combination with power The Keysight 81600B Tunable Laser
band Tunable Laser Sources are the meters and polarization instruments. Source Family can sweep as fast as
flagship models, featuring the widest These provide optimal swept- 80 nm/s with specified accuracy dur-
tuning range of 200 nm, respectively wavelength accuracy dynamic range. ing the sweep.
185 nm, with a single laser and a See the N7700A brochure for details.
70 dB/nm signal-to-source spontane- Realize the cost efficiency
ous emission ratio (signal-to-SSE Low SSE output port for and performance benefits in
ratio). The excellent low-SSE per- high dynamic range
formance typically allows crosstalk WDM component tests
measurements of better than The 81600B option 201, 200, 160, 150,
The testing of optical filters is based
70 dB/nm signal-to-source spontane- 140 and 130 Tunable Laser Sources
on a generic principle, namely the
ous emission ratio (signal-to-SSE are equipped with two optical
stimulus-response test. The state-
ratio). This and the high signal power outputs.
of-the-art approach is a wavelength-
permit measurements of wavelength The low-SSE output port of the resolved stimulus-response measure-
isolation to 100 dB, most often limited dual-output models delivers a signal ment utilizing a tunable laser source
by power meter sensitivity. with ultra-low source spontane- that is capable of fast and precise
ous emission. It enables accurate sweeps across the entire wavelength
Full wavelength range from crosstalk measurement of DWDM, range, and optical power meters.
1260 nm to 1640 nm CWDM and PON wavelength filtering
For DWDM components, high wave-
components by producing light only
The Keysight 81600B Tunable Laser length accuracy and dynamic range
at the desired wavelength.
Source Family offers the full wave- are critical. For CWDM and PON com-
length range from 1260 nm to The second output port provides ponents, a wide wavelength range,
1640 nm with no wavelength gaps. high optical power, adjustable over a dynamic range and tight costing are
The N7700A software suite has a power range of more than 60 dB via a key targets. If the investment in the
measurement engine for IL and PDL built-in optical attenuator. test solution can be shared among
that can combine the sweeps of up many different type of filters, the
to 3 tunable laser wavelength ranges. High power output for multi- contribution to each individual filter
Such a setup can be used for testing is minimized. In this way, cost targets
purpose component tests
CWDM multiplexers. for CWDM and PON components can
The Keysight 81600B Options 142 be met without sacrificing accuracy.
and 132 provide one output port with
O-band models for the latest high stimulus power for applications
Investing in the Keysight 81600B
applications Tunable Laser Source Family can
where the SSE level is not critical.
realize both the cost efficiency and
The 81600B options 130 and 132 The 81600B Option 142 can also performance benefits required.
cover the wavelength range from be equipped with a built-in optical
1260 nm to 1375 nm for an important attenuator, so providing an adjustable
set of applications. With the PMF
Polarization maintaining
power range of 60 dB.
output fiber, these are a good fiber for the test of
match for testing and developing integrated optical devices
Built-in wavelength meter for
components with silicon photonics
optimum tuning precision The 81600B Tunable Laser Source
technology. And especially with low-
Family is ideal for characterizing inte-
SSE, the Option 130 is the best tool The Keysight 81600B Tunable Laser grated optical devices. Its PMF output
for testing wavelength filters for LR4 Source Family includes a built-in real ports provide a well-defined state of
components. time wavelength meter which realizes polarization to ensure constant mea-
an absolute wavelength accuracy of surement conditions for waveguide
