Keysight Technologies
MIPI D-PHY Multilane Protocol
Triggering and Decode
For Infiniium Series Oscilloscopes


                                     Data Sheet
MIPI D-PHY

MIPI (Mobile Industry Processor Interface) serial buses are the backbone for communication in mobile products. The serial
bus interface provides content-rich points for debug and test. However, since these protocols transfer bits serially, using
a traditional oscilloscope has limitations. Manually converting captured 1's and 0's to protocol requires significant effort,
can't be done in real-time, and includes potential for human error. As well, traditional scope triggers are not sufficient for
specifying protocol-level conditions.

Extend your scope capability with the Keysight Technologies, Inc. MIPI D-PHY triggering and decode application. This
application makes it easy to debug and test designs that include MIPI D-PHY buses using your Infiniium Series oscilloscope.
