Image preview - the first page of the document



>> Download 5990-5299EN N5399C_252C N5399D HDMI Electrical Performance Validation and Compliance Software - Data Sheet c20140814 [20] documenatation <<

Text preview - extract from the document

Keysight Technologies
N5399C, N5399D HDMI Electrical Performance
Validation and Compliance Software
For Infiniium Series Oscilloscopes




                                     Data Sheet
Complete Physical Layer Testing for HDMI 1.4 and HDMI 2.0

The N5399C and N5399D HDMI               HDMI electrical tests, the package         are documented in the HDMI 2.0
electrical performance validation and    is designed to flexibly handle             Compliance Test Specification, or
compliance software is the complete      development tasks where your               CTS. The CTS defines the tests that
test execution environment for           characterization and troubleshooting       must be run on one or more of the
validating and troubleshooting the       efforts may dwarf those of the final       four high-speed TMDS (transition
electrical performance of HDMI 1.4 and   required testing for a passing device at   minimized differential signaling) lanes
HDMI 2.0 source devices. It operates     the conclusion of the project. Keysight    at each of the various resolution
on the Keysight Technologies Inc.        has designed this product to get you       settings for both specifications (HDMI
industry-performance-leading Infiniium   there faster.                              1.4b and HDMI 2.0). Using the HDMI
oscilloscope family, and extends and                                                Electrical Performance Validation and
improves the N5399B HDMI compliance      Whether your product is a DVD              Compliance (EPVC) software in the
test software already well-established   player, computer, graphics card,           development and pre-compliance steps
through the world's HDMI Authorized      or any of the other many product           will give you confidence in successful
Test Centers (ATCs).                     types that use the successful HDMI         outcome for the test process at the
                                         interface, you must submit your first      HDMI ATC. Upon completion, you may
Though its primary application is to     article HDMI product to an HDMI            become an HDMI self-certifier using
be the standard of HDMI physical         ATC for certification. Certification       your same documented test process
layer measurements in HDMI               requirements for the physical layer        and test equipment.
ATCs worldwide in executing the




                                                            2
                                                                HDMI EPVC software is easy to use
Features
                                                                The HDMI EPVC software extends the ease-of-use
                                                                advantages of Keysight's Infiniium oscilloscopes to the
The HDMI EPVC software is a full-featured product to            testing of HDMI designs. The Keysight automated test engine
simplify the validation of HDMI designs and includes:           walks you quickly and logically through the steps required to
                                                                define device capability, test selections, and test connection
