Image preview - the first page of the document



>> Download 5990-5363EN N9923A FieldFox RF Vector Network Analyzer - Data Sheet c20140730 [18] documenatation <<

Text preview - extract from the document

Keysight N9923A
FieldFox RF Vector Network Analyzer
2 MHz to 4/6 GHz



                                Data Sheet
Table of Contents
Definitions ...................................................................................................................... 2
FieldFox RF Vector Network Analyzer ....................................................................... 3
Cable and Antenna Analyzer (Option 305) ............................................................. 10
External USB Power Sensor Support (Option 302) ............................................... 10
Vector Voltmeter (Option 308) .................................................................................. 11
Block Diagram ............................................................................................................. 12
General Information.................................................................................................... 13
N9923A FieldFox RF VNA Options ........................................................................... 15
N9923A Upgrade Options .......................................................................................... 16
Calibration Kits ............................................................................................................ 16
FieldFox Data Link Software ..................................................................................... 17



Definitions
Specification (spec.)
Warranted performance. Specifications include guardbands to account for the
expected statistical performance distribution, measurement uncertainties, and
changes in performance due to environmental conditions. The following condi-
tions must be met:
