Image preview - the first page of the document



>> Download 5990-5823EN N1010A De-Embedding Software - Data Sheet c20140828 [2] documenatation <<

Text preview - extract from the document

Keysight N1010A FlexDCA Remote Access
Software
Expect More From Your Test Equipment

N1010A FlexDCA Remote Ac-
cess Software provides oscil-
loscope, eye/mask and jitter
mode measurement capabili-
ties on your PC. The powerful
new software application pro-
vides ofline and connected
measurement capability for
both the 86100C DCA-J and
86100D DCA-X oscilloscopes.



N1010A FlexDCA is the same advanced
user interface application that resides
on every 86100D DCA-X, but as a
standalone PC application it is more
"flexible". FlexDCA controls either
an 86100C or 86100D via a LAN                                                         located in an office location in another
connection, or it can also operate in an                                              part of the world. Imagine how
offline mode using saved waveforms or                                                 quickly you could help a colleague or
the built-in waveform simulator.                                                      contractor solve a problem in a remote
                                                                                      location if you could quickly and easily
                                                                                      take control of their instrument.
FlexDCA provides powerful
                                           InfiniiSim-DCA provides powerful
new insight for digital signals            de-embedding and embedding capabilities.
A variety of new measurement
                                           Remote Operation (via LAN)
capabilities provide designers with
tools to characterize high-speed digital   N1010A provides capabilities that are
designs more thoroughly and isolate        not available on an 86100C DCA-J,
problems more quickly.                     such as de-embedding or advanced
