Image preview - the first page of the document



>> Download 5990-6683EN InfiniiVision 3000 X-Series versus Tektronix TDS3000C Oscilloscopes - Competitive Comparison c20141029 [2] documenatation <<

Text preview - extract from the document

Product Fact Sheet
Keysight IniniiVision 3000 X-Series versus Tektronix TDS3000C Oscilloscopes

The Keysight Technologies, Inc. new 3000 X-Series
oscilloscopes use breakthrough technology to deliver
value, functionality and lexibility at prices that it into
existing budgets. Using a Keysight-designed MegaZoom
IV Custom ASIC technology, the 3000 X-Series provides
unprecedented signal visibility with over 1,000,000
waveforms per second. The 3000 X-Series is the industry's
irst 5-in-1 product with a full-featured scope, logic
analyzer, protocol analyzer, a function/arbitrary waveform
generator and integrated digital voltmeter all integrated
into one design with a large, 8.5-inch display.
                                                                                                    Keysight 3000 X-Series                        Tektronix TDS3000C
                                                              Bandwidth                             100 MHz, 200 MHz, 350 MHz,                    100 MHz, 300 MHz, 500 MHz   X
                                                                                                    500 MHz, 1 GHz
                                                              Upgradable bandwidth                  Yes                                           Not available               X
                                                              Maximum sampling rate                              1 2 3
                                                                                                    Up to 4 GSa/s , ,                             Up to 1.25 GSa/s1
                                                                                                                                                                              X
                                                                                                    Up to 5 GSa/s2, 4                             Up to 2.5 GSa/s2            X
                                                                                                                                                  Up to 5 GSa/s 3
                                                              Maximum memory depth                  4M                                            Up to 10 K                  X
                                                              Display                               8.5-inch WVGA (800 x 480)                     6.5-inch VGA (640 x 480)    X
                                                              Update rate                           > 1,000,000 wfms/s                            3,600 wfms/s                X
                                                              Mixed signal oscilloscope             Yes
