Image preview - the first page of the document



>> Download 5990-9020EN MIPI DigRF v4 (M-PHY) Protocol Triggering and Decode for Infiniium Series Oscilloscopes c20140827 [9] documenatation <<

Text preview - extract from the document

Keysight Technologies
MIPI DigRF v4 (M-PHY)
Protocol Triggering and Decode for
Infiniium Series Oscilloscopes




                  Data Sheet
MIPI DigRF v4 (M-PHY)


MIPI (Mobile Industry Processor Interface) serial buses                     The following are the MIPI DigRF v4 protocols and
are the backbone for communication in mobile products.                      features that will be supported by the application.
The serial bus interface provides content-rich points for                   1. Supports DigRF v4 v1.00.00 decode and triggering
debug and test. However, since these protocols transfer
                                                                            2. Decodes high-speed (HS-BURST) and low-speed
bits serially, using a traditional oscilloscope has limitations.
                                                                               (SYS-BURST) modes
Manually converting captured 1's and 0's to protocol requires
significant effort, can't be done in real-time, and includes                3. Decodes with and without cyclical redundancy check
potential for human error. As well, traditional scope triggers                 (CRC) support
are not sufficient for specifying protocol-level conditions.
                                                                            4. Supports decode on Tx and Rx packets
Extend your scope capability with the Keysight Technologies,                5. Supports search capability for various frames, sequence
Inc. MIPI DigRF v4 (M-PHY) triggering and decode applica-                      and errors
tion. This application makes it easy to debug and test
designs that include MIPI DigRF v4 buses using your
Infiniium Series oscilloscope.
