Image preview - the first page of the document



>> Download 5990-9109EN Infiniium 9000 Series vs. LeCroy WaveRunner 6Zi - Competitive Comparison c20140827 [2] documenatation <<

Text preview - extract from the document

Keysight Technologies                                             LeCroy WaveRunner 6Zi Series            Keysight Infiniium 9000 Series

Infiniium 9000 Series vs.
                            Bandwidth                             400 MHz, 600 MHz, 1 GHz, 2 GHz,         600 MHz, 1 GHz, 2.5 GHz, 4 GHz
                                                                  2.5 GHz, 4 GHz
                            Upgradable bandwidth                  No                                      Yes
LeCroy WaveRunner 6Zi       Max sample rate (2-ch)                Up to 20 GSa/s
                                                                  (40 GSa/s on 2.5 and 4 GHz models)
                                                                                                          Up to 20 GSa/s

Competitive Comparison      Standard/max memory (2-ch)            32 Mpts/256 Mpts                        40 Mpts/1 Gpts
                            Update rate                           110 wfm/s with 100 Kpts                 380 wfm/s with 100 Kpts
                            (table on reverse side)               12 wfm/s with 1 Mpts                    350 wfm/s with 1 Mpts
Keysight 9000 Series                                              1 wfm/s with 10 Mpts                    190 wfm/s with 10 Mpts
                            Biggest display                       12" WXGA                                15" (65% more display area)
                            Default setup and autoscale           No                                      Yes. All four vertical channel and
                            front panel buttons                                                           horizontal knobs
                            Knob per channel                      No (multiplexed knob controls)          Yes. All four vertical channel and
                                                                                                          horizontal knobs
                            Drag and drop measurements            No                                      Yes
                            Independently set sample rate         No                                      Yes
                            and memory depth
                            InfiniiScan Zone triggering           Not available                           Option. Up to 8 zones
                            12-bit models                         Yes (400 MHz and 600 MHz HRO models)    No. High-res mode up to 12-bit
LeCroy 6Zi Series                                                                                         resolution
                            Standard probes                       500 MHz passive                         500 MHz passive


                            MSO Comparison                        LeCroy WaveRunner 6Zi Series            Keysight Infiniium 9000 Series
                            Form factor                           External pod                            Integrated
                            MSO sample rate                       Up to 2 GSa/s                           Up to 2 GSa/s
                            MSO memory depth (std/max)            50 Mpts/50 Mpts                         128 Mpts/128 Mpts
                            Analog + digital pattern triggering   Yes, but with 39 ns trigger skew        Yes
                            Segmented memory support,             No for digital                          Yes
                            autoscale, FPGA app
 02 | Keysight | Infiniium 9000 Series vs. LeCroy WaveRunner 6Zi
