Image preview - the first page of the document
5990-9882EN E4982A LCR Meter 1 MHz to 3 GHz - Data Sheet c20140801 [22]


>> Download 5990-9882EN E4982A LCR Meter 1 MHz to 3 GHz - Data Sheet c20140801 [22] documenatation <<

Text preview - extract from the document
Keysight Technologies
E4982A LCR Meter
1 MHz to 3 GHz



                        Data Sheet
Definitions
Specification (spec.):
Warranted performance. Specifications include guardbands to account for the
expected statistical performance distribution, measurement uncertainties,
and changes in performance due to environmental conditions. Supplemental
information is intended to provide information that is helpful for using the
instrument but that is not guaranteed by the product warranty.


Typical (typ.):
Describes performance that will be met by a minimum of 80% of all products. It
is not guaranteed by the product warranty.


Supplemental performance data (SPD):
Represents the value of a parameter that is most likely to occur; the expected
mean or average. It is not guaranteed by the product warranty.


General characteristics:
A general, descriptive term that does not imply a level of performance.




                                                             2
Basic Measurement Characteristic
Measurement parameters
Impedance parameters                  |Z|, |Y|, Ls, Lp, Cs, Cp, Rs, Rp, X, G, B, D, Q,
