Image preview - the first page of the document



>> Download 5990-3769EN 9000 Series Oscilloscopes vs Tektronix 7000 Series Oscilloscopes - Competitive Comparison c20141028 [2] documenatation <<

Text preview - extract from the document

Competitive Comparison
Keysight Technologies Ininiium 9000 Series vs. Tektronix 7000C Series
                                                                Tektronix DPO 7000C Series               Keysight Ininiium 9000 Series

Keysight 9000 Series               Bandwidths Offered           500MHz, 1 GHz, 2.5 GHz, 3.5 GHz
                                                                (DSP boosted)
                                                                                                         600 MHz, 1 GHz, 2.5 GHz, 4 GHz

                                   Upgradeable bandwidth        No                                   X   Yes
                                   Max sample rate (2-ch)       up to 20 GSa/s                           up to 20 GSa/s
                                   Standard/Max memory (2-ch)   25 Mpts/250 Mpts                     X   40Mpts/1 Gpts
                                   Scope update rate            FastAcq mode to 250k wf/s (limita-       No DPX mode                               X
                                   (table on reverse side)      tions)
                                                                36 wf/s with 1 Kpts                  X   1000 wf/s with 1 Kpts
                                                                13 wf/s with 1 Mpts                  X   500 wf/s with 1 Mpt
                                   Biggest Display              12"                                  X   15" (40% more display area)
                                   Vertical/horizontal knobs:   Not offered                          X   Yes. All four vertical channel & horizontal
                                   Pushable vernier control                                              knobs.
                                   Drag and drop measurements   Not available                        X   Yes
Tektronix 7000C Series             Triggering stages            2 HW                                     1 HW + 1 SW                               X
                                   IniniiScan Zone Triggering   Not available                        X   Option. Up to 8 zones
                                   Standard Probes              500 MHz passive                          500 MHz passive
                                   Protocol features            decode on waveforms,                 X   lister, decode on waveforms, multi-tab
                                                                limited lister only                      view, decode entire record, segmented
                                                                                                         memory support


                                   MSO Comparison               Tektronix DPO 7000C Series               Keysight Ininiium 9000
                                   MSO Sample Rate                                                   X   2 GSa/s
                                   MSO memory depth (std/max)   No MSO                               X   128 Mpts/128 Mpts
Keysight | 9000 Series Oscilloscopes vs Tektronix 7000 Series Oscilloscopes
