Competitive Comparison
Keysight InfiniiVision 3000 X-Series versus Danaher-Tektronix MDO3000 Series Oscilloscopes

                                         Keysight Techologies, Inc. 3000 X-Series oscilloscopes use breakthrough technology to deliver value, functionality and
                                         flexibility at prices that fit into existing budgets. Using an Keysight-designed MegaZoom IV custom ASIC, the 3000 X-
                                         Series provides unprecedented signal visibility with a 1,000,000 waveforms-per-second update rate. The 3000 X-Series
                                         also offers uncompromised bandwidth, and segmented smart memory allows extended time captures and complements
                                         the always-on, responsive deep memory. Its low cost of ownership is solidified with a standard 2-year calibration cycle
                                         and excellent mean-time between failure (MTBF).

                                                                                Keysight 3000 X-Series                Danaher-Tektronix MDO3000
                                          Bandwidth                             100/200/350/500 MHz, 1 GHz            100/200/350/500 MHz, 1 GHz
                                          Maximum actual bandwidth              1 mV/div to 1.98 mV/div: 1 GHz        1 mV/div to 1.98 mV/div: 150 MHz       x
                                                                                2 mV/div to 4.98 mV/div: 1 GHz        2 mV/div to 4.98 mV/div: 350 MHz       x
                                                                                5 mV/div to 9.98 mV/div: 1 GHz        5 mV/div to 9.98 mV/div: 500 MHz       x
   InfiniiVision 3000 X-Series                                                  10 mV/div to 5 V/div: 1 GHz           10 mV/div to 5 V/div: 1 GHz
                                          Rise time (10-90% calc)               100 MHz:  3.5 nS                      100 MHz:  4 nS                         x
